GIDDINGS & LEWIS  502-03840-00伺服编码器模块 PDF资料

1.产 品 资 料 介 绍：

产品概述

GIDDINGS & LEWIS 502-03840-00 伺服编码器模块是一款高精度反馈装置，主要用于伺服系统中检测电机的旋转位置、速度及方向。该模块通过将机械运动转换为电信号，为伺服驱动器和控制器提供闭环控制所需的精确反馈信息，确保执行机构动作的高精度和高响应性。它适用于数控机床和工业自动化设备的精密运动控制场景。

技术参数（典型）

• 类型：增量型或绝对型编码器

• 分辨率：高分辨率脉冲输出，实现微米级定位精度

• 反馈信号：正交A/B信号及Z相参考脉冲

• 接口：工业标准接口，兼容G&L伺服驱动器及控制器

• 电源：标准工业电压，适用于多种机床环境

• 耐环境性：抗振动、抗冲击、耐高温及工业灰尘

• 机械安装：标准法兰和轴接口，便于快速安装和维护

应用场景

1. 数控机床

• 提供主轴、进给轴和刀库的精确位置反馈，实现高速高精度加工。

2. 伺服驱动系统

• 用于闭环控制，确保电机位置、速度及扭矩的实时调节。

3. 自动化生产线

• 监控执行机构运动，实现多工位动作同步与流程控制。

4. 工业机器人

• 提供机械手关节或末端工具的精确位置反馈，支持多轴联动。

5. 包装与印刷机械

• 实时反馈送料、切割和封装装置的位置，保证高速精密动作。

6. 纺织机械及卷绕设备

• 提供卷绕和张力控制装置的精确运动信息，确保工艺稳定性。

英文资料：

Product Overview

GIDINGS&LEWIS 502-03840-00 servo encoder module is a high-precision feedback device mainly used for detecting the rotational position, speed, and direction of motors in servo systems. This module converts mechanical motion into electrical signals, providing precise feedback information required for closed-loop control of servo drives and controllers, ensuring high precision and responsiveness of actuator actions. It is suitable for precision motion control scenarios of CNC machine tools and industrial automation equipment.

Technical parameters (typical)

Type: Incremental or Absolute Encoder

Resolution: High resolution pulse output, achieving micrometer level positioning accuracy

Feedback signal: Orthogonal A/B signal and Z-phase reference pulse

Interface: Industrial standard interface, compatible with G&L servo drives and controllers

Power supply: Standard industrial voltage, suitable for various machine tool environments

Environmental resistance: resistant to vibration, impact, high temperature, and industrial dust

Mechanical installation: Standard flange and shaft interface for quick installation and maintenance

Application scenarios

CNC machine tool

Provide precise position feedback for the spindle, feed axis, and tool magazine to achieve high-speed and high-precision machining.

Servo drive system

Used for closed-loop control to ensure real-time adjustment of motor position, speed, and torque.

Automatic production line

Monitor the movement of the executing mechanism to achieve multi station action synchronization and process control.

industrial robot

Provide precise position feedback for robotic arm joints or end tools, supporting multi axis linkage.

Packaging and Printing Machinery

Real time feedback on the position of feeding, cutting, and packaging devices to ensure high-speed and precise movements.

Textile machinery and winding equipment

Provide precise motion information for winding and tension control devices to ensure process stability.

2.产      品      展      示
