GIDDINGS & LEWIS  502-03B53-02遥控 I/O 驱动模块 PDF资料

1.产 品 资 料 介 绍：

产品概述

GIDDINGS & LEWIS 502-03B53-02 遥控 I/O 驱动模块是一款专用于远程输入输出控制的模块化接口单元。它能够接收控制器或上位系统的指令信号，通过远程输出接口驱动执行机构，同时将传感器和开关的状态反馈至控制系统，实现分布式或多点控制场景下的可靠动作执行和状态监测。该模块适用于复杂自动化系统及工业环境的远程控制需求。

技术参数（典型）

• 输入类型：数字量和模拟量信号输入，支持多通道采集

• 输出类型：数字量和模拟量输出，可驱动继电器、执行器及伺服模块

• 控制方式：远程控制或集中控制模式，支持上位系统指令通信

• 通讯接口：工业总线接口或专用控制接口

• 响应时间：高速信号处理，保证执行动作及时同步

• 保护功能：过流、过压、短路及信号异常保护

• 安装方式：模块化设计，便于机柜或机架集成

• 状态指示：LED显示各通道工作状态，便于监控和故障排查

应用场景

1. 远程数控机床控制

• 驱动机床的进给轴、主轴及辅助执行机构，实现远程动作控制与监控。

2. 分布式自动化生产线

• 在多工位或远程工位中控制执行器，实现动作同步和协调生产。

3. 工业机器人系统

• 远程控制机械手关节或末端工具，实现多点动作协调。

4. 包装与印刷设备

• 控制送料、切割、封装或印刷动作，支持远程监控与操作。

5. 纺织机械及卷绕设备

• 控制远程卷绕、走布及张力装置，保证生产工艺稳定。

6. 测试与实验平台

• 远程驱动伺服实验台或多轴测试装置，实现高精度动作控制和状态反馈。

英文资料：

Product Overview

GIDINGS&LEWIS 502-03B53-02 Remote I/O Driver Module is a modular interface unit designed specifically for remote input/output control. It can receive command signals from controllers or upper level systems, drive actuators through remote output interfaces, and provide feedback on the status of sensors and switches to the control system, achieving reliable action execution and status monitoring in distributed or multi-point control scenarios. This module is suitable for remote control requirements in complex automation systems and industrial environments.

Technical parameters (typical)

Input type: digital and analog signal input, supporting multi-channel acquisition

Output type: digital and analog output, can drive relays, actuators, and servo modules

Control mode: remote control or centralized control mode, supporting communication of instructions from the upper system

Communication interface: industrial bus interface or dedicated control interface

Response time: High speed signal processing ensures timely synchronization of execution actions

Protection function: overcurrent, overvoltage, short circuit, and signal abnormality protection

Installation method: Modular design, convenient for cabinet or rack integration

Status indication: LED displays the working status of each channel for easy monitoring and troubleshooting

Application scenarios

Remote control of CNC machine tools

Drive the feed axis, spindle, and auxiliary actuator of the machine tool to achieve remote action control and monitoring.

Distributed automation production line

Control actuators in multiple or remote workstations to achieve action synchronization and coordinated production.

Industrial Robot System

Remote control of robotic arm joints or end tools to achieve coordinated multi-point movements.

Packaging and Printing Equipment

Control feeding, cutting, packaging or printing actions, support remote monitoring and operation.

Textile machinery and winding equipment

Control remote winding, feeding, and tension devices to ensure stable production processes.

Testing and experimental platform

Remote drive servo test bench or multi axis testing device to achieve high-precision motion control and state feedback.

2.产      品      展      示
