GIDDINGS & LEWIS 503-19515-20执行控制板  PDF资料

1.产 品 资 料 介 绍：

产品概述

GIDDINGS & LEWIS 503-19515-20 执行控制板是一款专为工业自动化及数控机床设计的核心控制模块。它用于接收上位控制器的指令，并对伺服驱动器、步进电机、液压或气动执行装置进行精确控制，实现机床或生产设备的动作执行与协调控制。该控制板能够在高速、高精度及复杂动作序列中保证可靠运行。

技术参数（典型）

• 控制类型：脉冲输出、方向控制及逻辑执行

• 输入接口：接收来自主控制器或逻辑模块的指令

• 输出接口：驱动多路执行装置，包括伺服、继电器及步进驱动器

• 信号兼容性：工业标准电平，如 24VDC

• 响应速度：高速脉冲输出，适合多轴同步控制

• 保护机制：过载、短路、过压及信号异常保护

• 安装方式：模块化插卡式，可便捷安装在控制机柜或机架

• 状态指示：LED显示各通道工作状态，便于调试和故障诊断

应用场景

1. 数控机床

• 控制进给轴、主轴及刀库，实现精密加工和自动换刀功能。

2. 自动化生产线

• 驱动装配、输送、分拣设备，实现高效同步操作。

3. 工业机器人

• 控制机器人关节或末端执行器，实现多轴精确运动。

4. 包装与印刷机械

• 驱动送料、切割、封装等设备，实现高速高精度生产。

5. 纺织机械

• 控制卷绕、张力、走布装置，提高生产效率和工艺稳定性。

6. 实验与测试平台

• 用于伺服测试台、多轴实验装置，实现精确动作控制和数据采集。

英文资料：

Product Overview

GIDINGS&LEWIS 503-19515-20 Execution Control Board is a core control module designed specifically for industrial automation and CNC machine tools. It is used to receive instructions from the upper controller and perform precise control on servo drives, stepper motors, hydraulic or pneumatic actuators, achieving action execution and coordinated control of machine tools or production equipment. This control board can ensure reliable operation in high-speed, high-precision, and complex motion sequences.

Technical parameters (typical)

Control type: pulse output, direction control, and logic execution

Input interface: receives instructions from the main controller or logic module

Output interface: Drive multiple execution devices, including servo, relay, and stepper drivers

Signal compatibility: Industrial standard level, such as 24VDC

Response speed: High speed pulse output, suitable for multi axis synchronous control

Protection mechanism: Overload, short circuit, overvoltage, and signal abnormality protection

Installation method: Modular plug-in card, easy to install in control cabinets or racks

Status indication: LED displays the working status of each channel for easy debugging and fault diagnosis

Application scenarios

CNC machine tool

Control the feed axis, spindle, and tool magazine to achieve precision machining and automatic tool changing functions.

Automatic production line

Drive assembly, conveying, and sorting equipment to achieve efficient synchronous operation.

industrial robot

Control robot joints or end effectors to achieve precise multi axis motion.

Packaging and Printing Machinery

Drive feeding, cutting, packaging and other equipment to achieve high-speed and high-precision production.

textile machinery

Control winding, tension, and feeding devices to improve production efficiency and process stability.

Experimental and testing platform

Used for servo test benches and multi axis experimental devices to achieve precise motion control and data acquisition.

2.产      品      展      示
