GIDDINGS & LEWIS 502-03642-03输入分析模块 PDF资料

1.产 品 资 料 介 绍：

产品概述

GIDDINGS & LEWIS 502-03642-03 输入分析模块是一款专用于工业自动化和数控系统的信号处理模块。它用于采集和分析来自传感器、开关或其他输入设备的信号，并将处理后的数据传递给控制器，从而实现高精度、高可靠的设备控制。

产品应用领域

1. 高精度数控机床

• 用于采集主轴位置、限位开关、刀具状态等多路输入信号，实现加工动作精确控制与安全保护。

2. 自动化装配线

• 分析装配工位传感器、光电开关和安全门状态，实现装配过程的逻辑判断和动作触发。

3. 工业机器人系统

• 采集末端工具、夹具及安全传感器的输入信号，支持机器人多轴运动的协调与精确执行。

4. 包装与印刷设备

• 处理纸张、薄膜或包装件位置传感器信号，保证送料、切割和封装动作的同步与精准。

5. 能源与过程控制设备

• 对温度、压力、流量等传感器信号进行实时采集与分析，为自动化控制系统提供准确反馈。

6. 物料搬运与仓储系统

• 分析输送带、堆垛机、升降机传感器输入，实现物料流转的精确控制与安全监控。

7. 实验与检测平台

• 在测试台或实验室设备中用于采集多路模拟或数字输入信号，为实验数据分析和设备控制提供支持。

英文资料：

Product Overview

GIDINGS&LEWIS 502-03642-03 Input Analysis Module is a signal processing module specifically designed for industrial automation and numerical control systems. It is used to collect and analyze signals from sensors, switches, or other input devices, and transmit the processed data to the controller to achieve high-precision and highly reliable device control.

Product application areas

High precision CNC machine tool

Used to collect multiple input signals such as spindle position, limit switch, tool status, etc., to achieve precise control and safety protection of machining actions.

Automated assembly line

Analyze the status of assembly station sensors, photoelectric switches, and safety doors to achieve logical judgment and action triggering during the assembly process.

Industrial Robot System

Collect input signals from end tools, fixtures, and safety sensors to support coordinated and precise execution of robot multi axis movements.

Packaging and Printing Equipment

Process position sensor signals for paper, film, or packaging to ensure synchronous and accurate feeding, cutting, and packaging actions.

Energy and Process Control Equipment

Real time collection and analysis of sensor signals such as temperature, pressure, and flow rate to provide accurate feedback for automation control systems.

Material handling and warehousing system

Analyze the sensor inputs of conveyor belts, stackers, and elevators to achieve precise control and safety monitoring of material flow.

Experimental and Testing Platform

Used in test benches or laboratory equipment to collect multiple analog or digital input signals, providing support for experimental data analysis and equipment control.

2.产      品      展      示
