Z8536 CIO Device
The Z8536 CIO device complements the Z85230 ESCC by supplying
modem control lines not provided by the Z85230 ESCC. In addition, the
Z8536 CIO device has three independent 16-bit counters/ timers. The
Z85230 receives a 5 MHz clock input.
Base Module Feature Register
The Base Module Feature Register contains the details of the
MVME2603/2604 single board computer’s configuration. It is an 8-bit
read-only register located on the base board at ISA I/OSCCP∗ Z85230 ESCC present. If set, there is no on-board
synchronous serial support (the ESCC is not present). If
cleared, the Z85230 ESCC is installed and there is on-board
support for synchronous serial communication.
PMC2P∗ PMC/PMCIX slot 2 present. If set, no PCI mezzanine card (or
PCI expansion device) is installed in PMC slot 2. If cleared,
PMC/PMCIX slot 2 contains a PCI mezzanine card (or PCI
expansion device).
PMC1P∗ PMC slot 1 present. If set, no PCI mezzanine card is installed
in PMC slot 1. If cleared, PMC slot 1 contains a PCI
mezzanine card.
VMEP∗ VMEbus present. If set, there is no VMEbus interface. If
cleared, the VMEbus interface is supported.
LANP∗ Ethernet present. If set, no Ethernet transceiver interface is
installed. If cleared, there is on-board Ethernet support.SCSI present. If set, there is no on-board SCSI interface. If
cleared, on-board SCSI is supported.
P2 Signal Multiplexing
Due to the limited supply of available pins in the P2 backplane connectors
of MVME2603/2604 models that are configured for MVME761 I/O mode,
certain signals are multiplexed through VMEbus connector P2 for
additional I/O capacity.
The signals affected are synchronous I/O control signals that pass between
the base board and the MVME761 transition module. The multiplexing is
a hardware function that is entirely transparent to software.
Four signals are involved in the P2 multiplexing function: MXDO, MXDI,
MXCLK, and MXSYNC∗.
MXDO is a time-multiplexed data output line from the main board and
MXDI is a time-multiplexed line from the MVME761 module. MXCLK
is a 10 MHz bit clock for the MXDO and MXDI data lines. MXSYNC∗ is
asserted for one bit time at time slot 15 (Table 3-2) by the
MVME2603/2604 base board. The MVME761 transition module uses
MXSYNC∗ to synchronize with the base board.
A 16-to-1 multiplexing scheme is used with MXCLK’s 10 MHz bit rate.
16 time slots are defined and allocated as follows:
