Magnetek 1980-103-R-DP-TD2 旋转凸轮限位开关 PDF资料
1.产 品 资 料 介 绍：
产品特点
模块化结构
具有可更换凸轮模块，便于维修与扩展。
每个凸轮可独立调整，适用于多点限位控制需求。
高耐久性设计
采用工业级耐磨材料，机械寿命长，适用于高频率操作。
内部微动开关寿命高，确保长时间稳定运行。
防护性能优良
外壳具备防尘、防油、防水结构，适合严苛环境使用。
适用于户外、潮湿、粉尘或油气较多的工作现场。
多通道限位功能
支持2~6个限位点控制，用于复杂运动路径的精准限位。
可实现“慢速停车点”与“终点停机”等多段控制策略。
精确调整机构
凸轮角度调整范围为360°，带刻度定位，调节方便。
支持现场快速设定，无需专业工具。
双极（DP）接点设计
双极开关结构，提升电气安全性，适用于重要位置保护控制。
可实现主回路与控制回路的独立切断功能。
电气接口通用性强
适配常见交流或直流电压等级，便于与PLC、继电器等系统集成。
英文资料：
Product Features
Modular structure
Equipped with replaceable cam modules for easy maintenance and expansion.
Each cam can be independently adjusted, suitable for multi-point limit control requirements.
High durability design
Using industrial grade wear-resistant materials with long mechanical life, suitable for high-frequency operation.
The internal micro switch has a high lifespan, ensuring long-term stable operation.
Excellent protective performance
The shell has dust-proof, oil proof, and waterproof structures, suitable for use in harsh environments.
Suitable for outdoor, humid, dusty or oily work sites.
Multi channel limit function
Supports 2-6 limit point controls for precise positioning of complex motion paths.
It can implement multi-stage control strategies such as "slow parking point" and "end stop".
Accurately adjust the mechanism
The cam angle adjustment range is 360 °, with scale positioning for easy adjustment.
Support quick on-site setup without the need for professional tools.
Bipolar (DP) contact design
The bipolar switch structure enhances electrical safety and is suitable for protecting and controlling important positions.
It can achieve independent disconnection function between the main circuit and the control circuit.
Strong universality of electrical interfaces
Adapt to common AC or DC voltage levels, making it easy to integrate with systems such as PLCs and relays.
2.产 品 展 示
