Magnetek ETC620014-S019驱动板组件 PDF资料
1.产 品 资 料 介 绍：
Magnetek ETC620014‑S019 驱动板组件
产品概述与应用领域
一、产品概述
Magnetek ETC620014‑S019 是一款工业级驱动板组件，广泛用于 Magnetek/Yaskawa 伺服控制系统中，负责接收控制指令并驱动功率部分对伺服电机或主轴电机进行控制。该组件通常作为内部控制电路板，集成于伺服驱动器中，用于实现对速度、位置和扭矩的精密调节。
二、应用领域
数控机床（CNC 系统）
用于控制主轴电机或伺服电机，实现高速、高精度加工操作。
保证轴向定位精准，提升零件加工质量与一致性。
工业机器人与自动化设备
驱动工业机器人关节或线性滑台电机，实现精密动作控制。
可支持复杂路径执行和多轴协调运动控制。
激光/等离子/冲压设备
控制执行机构的移动电机，实现高频响应和精密运行。
在切割、打标或高速冲床系统中实现快速启停和高重复精度。
印刷与包装机械
作为电机控制单元使用，调节速度、张力等参数以配合工艺要求。
保证生产流程稳定，防止偏移或速度波动导致的缺陷。
维修替换与技术升级
适用于替代原驱动器中损坏或老化的控制板组件，恢复设备正常运行。
常用于在役老旧系统的维护延寿或局部改造。
英文资料：
Magnetek ETC620014-S019 Driver Board Component
Product Overview and Application Fields
1、 Product Overview
Magnetek ETC620014-S019 is an industrial grade drive board component widely used in Magnetek/Yaskawa servo control systems, responsible for receiving control commands and driving the power part to control servo motors or spindle motors. This component is typically used as an internal control circuit board, integrated into servo drives, to achieve precise adjustment of speed, position, and torque.
2、 Application Fields
Numerical Control Machine Tool (CNC System)
Used to control spindle motors or servo motors to achieve high-speed and high-precision machining operations.
Ensure accurate axial positioning and improve the quality and consistency of part processing.
Industrial robots and automation equipment
Drive industrial robot joints or linear slide motors to achieve precise motion control.
Can support complex path execution and multi axis coordinated motion control.
Laser/plasma/stamping equipment
Control the mobile motor of the actuator to achieve high-frequency response and precise operation.
Realize fast start stop and high repeatability accuracy in cutting, marking or high-speed punching systems.
Printing and packaging machinery
As a motor control unit, adjust parameters such as speed and tension to meet process requirements.
Ensure stable production process and prevent defects caused by deviation or speed fluctuations.
Repair, replacement, and technical upgrade
Suitable for replacing damaged or aged control board components in the original drive and restoring normal equipment operation.
Commonly used for the maintenance and extension of service life or partial renovation of old systems in service.
2.产 品 展 示
