On the MVME2603/2604 base board, the standard serial console port
(COM1) serves as the PPCBug debugger console port. The firmware
console should be set up as follows:
❏ Eight bits per character
❏ One stop bit per character
❏ Parity disabled (no parity)
❏ Baud rate of 9600 baud9600 baud is the power-up default for serial ports on MVME2603/2604
boards. After power-up you can reconfigure the baud rate if you wish,
using the PPCBug PF (Port Format) command via the command line
interface. Whatever the baud rate, some type of hardware handshaking —
either XON/OFF or via the RTS/CTS line — is desirable if the system
supports it.Introduction
This chapter supplies information for use of the MVME2603/2604 family
of Single Board Computers in a system configuration. Here you will find
the power-up procedure and descriptions of the switches and LEDs,
memory maps, and software initialization.
Applying Power
After you have verified that all necessary hardware preparation has been
done, that all connections have been made correctly, and that the
installation is complete, you can power up the system. The MPU,
hardware, and firmware initialization process is performed by the
PowerPC PPCBug power-up or system reset. The firmware initializes the
devices on the SBC module in preparation for booting the operating
system.
The firmware is shipped from the factory with an appropriate set of
defaults. In most cases there is no need to modify the firmware
configuration before you boot the operating system.
The following flowchart shows the basic initialization process that takes
place during PowerPC system startup.
For further information on PPCBug, refer to Chapter 5, PPCBug; to
Appendix C, Troubleshooting CPU Boards: Solving Startup Problems; or
to the PPCBug Firmware Package User’s Manual, listed in Appendix D,
Related Documentation.The MVME2603/2604 front panel has ABORT and RESET switches and six
LED (light-emitting diode) status indicators (CHS, BFL, CPU, PCI, FUS,
SYS). The switches and LEDs are mounted on an LED mezzanine board
that plugs into the base board.
