VIBRO 200-510-017-017工控产品,说明书
在通电的情况下插入或拆卸模块可能会导致损坏至模块组件。
在这种情况下，存在可能导致死亡的危险电压设备搬运、测试和调整时要格外小心。
3.小心地将MVME2603/2604从其VMEbus卡插槽中卸下将其平放，使接头P1和P2面向您。
避免接触集成电路的区域；静电放电会损坏这些电路。
VIBRO 200-510-017-017工控产品4、将RAM200夹层模块放置在基板顶部。RAM200下侧的接头J9应连接将相应的接头J7平稳地安装在MVME2603/2604。图1-18。在MVME2603/2604上放置RAM200
5.将四个短十字螺钉穿过拐角处的孔进入MVME2603/2604的对峙状态。拧紧螺钉。
6.将MVME2603/2604组件重新安装到其正确的卡槽中。是确保模块正确安装在背板连接器中。不要损坏或弯曲接头针脚。
7.更换机箱或系统护盖，将系统重新连接到交流或直流电源，并打开设备电源。
PMC模块安装PCI夹层卡（PMC）模块安装在RAM200旁边MVME2603/2604基板顶部的夹层。安装PMC模块，参考图1-19，并按以下步骤进行：图1-19。MVME2603/2604上的PMC模块放置5、将PMC模块的边缘连接器滑入前面板从后面打开并将PMC模块放置在基座顶部板PMC模块下侧的四个接头然后应与相应的连接器平滑连接（J11/12/13/14）在MVME2603/2604上。6.将两个短Phillips螺钉穿过前部的孔PMC模块的角落，进入MVME2603/2604。拧紧螺钉。7.将MVME2603/2604组件重新安装到其正确的卡槽中。是确保模块正确安装在背板连接器中。不要损坏或弯曲接头针脚。8.更换机箱或系统护盖，将系统重新连接到交流或直流电源，并打开设备电源
Inserting or removing modules with power applied may result in damage
to module components.
!
Warning
Dangerous voltages, capable of causing death, are present in this
equipment. Use extreme caution when handling, testing, and adjusting.
3. Carefully remove the MVME2603/2604 from its VMEbus card slot
and lay it flat, with connectors P1 and P2 facing you.
!
Caution
Avoid touching areas of integrated circuitry; static discharge can damage
these circuits.
4. Place the RAM200 mezzanine module on top of the base board.
Connector J9 on the underside of the RAM200 should connect
smoothly with the corresponding connector J7 on the
MVME2603/2604.Figure 1-18. RAM200 Placement on MVME2603/2604
5. Insert the four short Phillips screws through the holes at the corners
of the RAM200, into the standoffs on the MVME2603/2604.
Tighten the screws.
6. Reinstall the MVME2603/2604 assembly in its proper card slot. Be
sure the module is well seated in the backplane connectors. Do not
damage or bend connector pins.
7. Replace the chassis or system cover(s), reconnect the system to the
AC or DC power source, and turn the equipment power on.
PMC Module Installation
PCI mezzanine card (PMC) modules mount beside the RAM200
mezzanine on top of the MVME2603/2604 base board. To install a PMC
module, refer to Figure 1-19 and proceed as follows:Figure 1-19. PMC Module Placement on MVME2603/2604
5. Slide the edge connector of the PMC module into the front panel
opening from behind and place the PMC module on top of the base
board. The four connectors on the underside of the PMC module
should then connect smoothly with the corresponding connectors
(J11/12/13/14) on the MVME2603/2604.
6. Insert the two short Phillips screws through the holes at the forward
corners of the PMC module, into the standoffs on the
MVME2603/2604. Tighten the screws.
7. Reinstall the MVME2603/2604 assembly in its proper card slot. Be
sure the module is well seated in the backplane connectors. Do not
damage or bend connector pins.
8. Replace the chassis or system cover(s), reconnect the system to the
AC or DC power source, and turn the equipment power on
