GE MIVII1000E00HI00 继电器保护器 PDF资料
1.产 品 资 料 介 绍：
中文资料：
MIVII1000E00HI00 继电器保护器 是一种用于电力系统中的智能继电保护装置，主要用于监测和保护电力设备（如变压器、发电机、输电线路等），通过检测电流、电压及其他电参数，实现故障检测、保护动作和报警功能，保障电力系统的安全稳定运行。
一、产品概述
型号：MIVII1000E00HI00
类型：继电器保护器 / 继电保护装置
应用：电力系统设备的过流、过压、欠压、差动保护等多种保护功能
制造商：具体厂家不详，型号结构类似于部分电力保护装置品牌产品编码
二、主要功能
多功能保护：支持过流保护、欠压保护、过压保护、差动保护、接地保护等多种保护方式。
故障检测与报警：实时监测电力系统运行状态，发生异常及时报警。
动作控制：在检测到故障时，快速发出跳闸指令，切断故障线路。
数据记录与通讯：部分型号支持事件记录和通讯接口，实现远程监控和数据采集。
用户界面：带液晶显示屏或LED指示，便于现场查看运行状态和故障信息。
三、典型应用场景
输变电线路保护
发电机及变压器保护
配电网自动化系统
工业厂矿电气设备保护
智能电网和微网保护
英文资料：
MIVII1000E00HI00 relay protector is an intelligent relay protection device used in power systems, mainly for monitoring and protecting power equipment (such as transformers, generators, transmission lines, etc.). By detecting current, voltage, and other electrical parameters, it achieves fault detection, protection action, and alarm functions, ensuring the safe and stable operation of the power system.
1、 Product Overview
Model: MIVII1000E00HI00
Type: Relay protector/relay protection device
Application: Multiple protection functions such as overcurrent, overvoltage, undervoltage, and differential protection for power system equipment
Manufacturer: The specific manufacturer is unknown, and the model structure is similar to that of some power protection device brands and product codes
2、 Main functions
Multi functional protection: supports multiple protection methods such as overcurrent protection, undervoltage protection, overvoltage protection, differential protection, and grounding protection.
Fault detection and alarm: Real time monitoring of the operation status of the power system, and timely alarm in case of abnormalities.
Action control: When a fault is detected, quickly issue a trip command to cut off the faulty line.
Data recording and communication: Some models support event recording and communication interfaces, enabling remote monitoring and data collection.
User interface: Equipped with a LCD display or LED indicator for easy on-site viewing of operational status and fault information.
3、 Typical application scenarios
Protection of transmission and transformation lines
Generator and transformer protection
Distribution automation system
Protection of electrical equipment in industrial plants and mines
Smart grid and microgrid protection
2.产 品 展 示
