Tokyo Electron CS1B14-000011-12交换器 PDF资料
1.产 品 资 料 介 绍：
中文资料：
Tokyo Electron (TEL) CS1B14-000011-12 交换器 — 产品应用领域详解
一、产品功能定位
CS1B14-000011-12 交换器是 Tokyo Electron 半导体设备系统中用于数据通信与网络连接的工业以太网交换机模块，其主要功能是为设备内部多个子系统之间提供高速、稳定的网络通信平台，保障控制信息、工艺数据、监控信号的高效传输与同步。
二、主要应用领域
1. 半导体设备内部控制网络通信核心
设备类型：
光刻设备（Lithography）
CVD/Etch 系统
显影与清洗系统（Coater/Developer）
自动化搬运平台（FOUP Loaders、Transfer Modules）
功能作用：
连接主控制器（如 IPC、PLC）与各 I/O 板、传感器、执行器；
实现分布式控制系统间的数据互通，确保设备运行实时性与同步性。
2. 工艺数据采集与传输平台
应用场景：
将实时工艺数据（温度、气压、电流、位置等）快速传送至控制主机；
配合人机界面（HMI）、数据库或 MES 系统，实现数据记录与分析。
典型接口：
RJ45 千兆/百兆以太网口；
部分版本可能支持光纤 SFP 接口、工业级 PoE 供电。
英文资料：
Tokyo Electron (TEL) CS1B14-00011-12 Converter - Product Application Field Detailed Explanation
1、 Product functional positioning
CS1B14-00011-12 switch is an industrial Ethernet switch module used for data communication and network connection in Tokyo Electron semiconductor equipment systems. Its main function is to provide a high-speed and stable network communication platform for multiple subsystems within the equipment, ensuring efficient transmission and synchronization of control information, process data, and monitoring signals.
2、 Main application areas
1. Communication core of internal control network in semiconductor equipment
Equipment type:
Lithography equipment
CVD/Etch system
Coater/Developer System
Automated Handling Platforms (FOUP Loaders, Transfer Modules)
Function and function:
Connect the main controller (such as IPC, PLC) with various I/O boards, sensors, and actuators;
Realize data interoperability between distributed control systems to ensure real-time and synchronous operation of equipment.
2. Process data collection and transmission platform
Application scenarios:
Quickly transmit real-time process data (temperature, air pressure, current, position, etc.) to the control host;
Collaborate with human-machine interface (HMI), database or MES system to achieve data recording and analysis.
Typical interface:
RJ45 Gigabit/100Mbps Ethernet port;
Some versions may support fiber optic SFP interfaces and industrial grade PoE power supply.
