MOTOROLA 0100RSDPMC-J板卡配置教程
如果连续块内存大小为64KB，在中找不到内存搜索指定的范围起始地址和内存搜索结束地址参数，然后bug将其工作页面放在上的车载静态RAMMVME187。默认内存搜索结束地址是计算的大小本地内存。在出现错误之前不会有任何延迟开始搜索工作页。
以下VMEbus磁盘/磁带控制器模块是由187Bug支持。每个控制器的默认地址类型是第一个地址，控制器可以由第一个在命令BH、BO或IOP期间或在陷阱#496期间CLUN电话。
MOTOROLA 0100RSDPMC-J板卡DSKRD或。DSKWR。注意，如果使用相同类型的另一个控制器，则第二个必须通过车载跳线和/或开关，使其与第二个地址匹配，并且可以通过第二个CLUN。支持的VMEbus网络控制器模块MVME187Bug如表C-1所示。每个的默认地址显示类型和位置以指示控制器必须安装的位置由MVME187Bug支持。CLUN和DLUN与以下部件一起使用调试器命令和调试器系统调用：❏ 在寻求帮助之前，请尝试以下简单的故障排除步骤或者将CPU板送回维修。
❏ 一些程序会将电路板退回工厂调试器环境。（董事会根据这些条款进行了测试。）出厂前的情况。）❏ 自检可能无法在所有用户自定义的环境中运行。1、确保系统已接通电源。2、检查电路板是否牢固安装在其内部背板或机箱。3.检查所有必要的电缆是否连接到董事会，根据本手册。4、检查是否符合系统要求注意事项，见第3章。审查安装和启动程序，在第3章中。逐步通电例行程序你的黑板在第3-17页。试试看。B、 如果LED都亮了，董事会可能在错误的插槽。1.CPU板应位于第一个（最左边）插槽（如果它是系统控制器）。2、“系统控制器”功能要求：
收割台J2设置正确。见第3章。
If a contiguous block of
memory, 64KB in size, is not found in
the range specified by Memory Search
Starting Address and Memory Search
Ending Address parameters, then the
bug will place its work page in the
onboard static RAM on the
MVME187. Default Memory Search
Ending Address is the calculated size
of local memory. There will be no delay before the Bug
begins its search for a work page.
The following VMEbus disk/tape controller modules are
supported by the 187Bug. The default address for each controller
type is First Address and the controller can be addressed by First
CLUN during commands BH, BO, or IOP, or during TRAP #496
calls .DSKRD or .DSKWR.
Note that if another controller of the same type is used, the second
one must have its address changed by its onboard jumpers and/or
switches, so that it matches Second Address and can be called up by
Second CLUN.The VMEbus network controller modules supported by
MVME187Bug are shown in Table C-1. The default address for each
type and position is shown to indicate where the controller must
reside to be supported by MVME187Bug.
The CLUNs and DLUNs are used in conjunction with the following
debugger commands and debugger system calls:❏ Try these simple troubleshooting steps before calling for help
or sending your CPU board back for repair.
❏ Some of the procedures will return the board to the factory
debugger environment. (The board was tested under these
conditions before it left the factory.)
❏ Selftest may not run in all user-customized environments.1. Make sure the system is plugged in.
2. Check that the board is securely installed in its
backplane or chassis.
3. Check that all necessary cables are connected to
the board, per this manual.
4. Check for compliance with System
Considerations, in Chapter 3.
5. Review the Installation and Startup procedures,
in Chapter 3. The step-by-step powerup routine
for your board is on page 3-17. Try it.
B. If the LEDs
are lit, the board
may be in the
wrong slot.
1. The CPU board should be in the first (leftmost)
slot if it is to be the system controller.
2. The “system controller” function requires that
header J2 be set properly. See Chapter 3.
