Tokyo Electron 3D08-000020-12印刷电路板 PDF资料
1.产 品 资 料 介 绍：
中文资料：
产品名称：3D08-000020-12 印刷电路板
制造商：Tokyo Electron Ltd.（东京电子）
产品类型：印刷电路板（Printed Circuit Board）
一、产品概述
3D08-000020-12 是 Tokyo Electron 设备中使用的一款专用印刷电路板，主要承载各种电子元件，用于实现信号处理、控制逻辑、接口传输等功能。该 PCB 可能作为某一功能模块的核心电路基板，在设备中承担数据传输和控制信号的关键作用。
二、主要功能
电子元件载体
支持安装电阻、电容、集成芯片、接口连接器等元件，构成完整的电子电路。
信号处理
实现输入信号的调理、放大、转换以及输出信号的驱动。
接口连接
提供模块间或设备间的电气连接点，支持总线通信或点对点连接。
电源管理
具备电压稳压、滤波和保护电路，保证电路板稳定工作。
三、典型应用场景
该 PCB 常见于 Tokyo Electron 半导体制造设备中的以下系统模块：
控制单元的子电路板
I/O 信号处理模块
功率调节与驱动模块
传感器接口板
英文资料：
Product Name: 3D08-000020-12 Printed Circuit Board
Manufacturer: Tokyo Electron Ltd
Product type: Printed Circuit Board
1、 Product Overview
3D08-000020-12 is a specialized printed circuit board used in Tokyo Electron equipment, mainly carrying various electronic components for signal processing, control logic, interface transmission and other functions. This PCB may serve as the core circuit substrate for a certain functional module, playing a critical role in data transmission and control signals in the device.
2、 Main functions
Electronic component carrier
Support the installation of resistors, capacitors, integrated chips, interface connectors, and other components to form a complete electronic circuit.
Signal Processing
Realize the conditioning, amplification, conversion of input signals, and driving of output signals.
Interface connection
Provide electrical connection points between modules or devices, supporting bus communication or point-to-point connections.
Power management
Equipped with voltage stabilization, filtering, and protection circuits to ensure stable operation of the circuit board.
3、 Typical application scenarios
This PCB is commonly used in the following system modules of Tokyo Electron semiconductor manufacturing equipment:
Sub circuit board of control unit
I/O signal processing module
Power regulation and drive module
Sensor interface board
