ABB 1MRK001608-CAr02中央控制器模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
产品型号：1MRK001608-CAr02
产品名称：中央控制器模块（Central Controller Module）
制造商：ABB
归属系统：用于 ABB 高端继电保护及变电站自动化设备中（如 REL/REF/RET 系列）
一、功能定位
主控逻辑中心
模块作为设备的“中央处理器”，执行核心逻辑运算、控制策略、事件判断、保护动作等。
协调通信与数据流
管理与通信模块、电源模块、I/O 模块等的协调工作，实现指令分发与状态汇总。
保护动作决策处理
根据输入信号（如电流、电压、频率等），执行过流、差动、低压等保护策略的快速判定。
事件与记录管理
负责记录故障发生前后状态，输出事件顺序记录（SOE）、故障录波等重要信息。
二、应用领域
高压输电系统继电保护设备
安装于 ABB REL670、REF615、RET670 等智能电子装置中，作为主控制核心模块。
数字变电站系统（IEC 61850 环境）
在自动化控制系统中作为协调中心，与SCADA、HMI、通信网关进行接口联动。
电网保护与自动切换系统
用于管理断路器跳合闸、母线切换、电源转换等关键操作。
发电厂和工业变配电站自动保护系统
应用于关键能源与工业基础设施场所，保证系统安全与可靠运行。
英文资料：
Product model: 1MRK001608-CAr02
Product Name: Central Controller Module
Manufacturer: ABB
Belonging system: used in ABB high-end relay protection and substation automation equipment (such as REL/REF/RET series)
1、 Functional positioning
Main control logic center
The module serves as the "central processing unit" of the device, executing core logical operations, control strategies, event judgments, protection actions, etc.
Coordinate communication and data flow
Coordinate the management and communication modules, power modules, I/O modules, etc. to achieve instruction distribution and status summary.
Protection action decision processing
Based on input signals such as current, voltage, frequency, etc., perform rapid determination of overcurrent, differential, low-voltage and other protection strategies.
Event and Record Management
Responsible for recording the status before and after the occurrence of faults, outputting important information such as sequence of events (SOE), fault waveform recording, etc.
2、 Application Fields
Relay protection equipment for high-voltage transmission system
Installed in ABB REL670, REF615, RET670 and other intelligent electronic devices as the main control core module.
Digital Substation System (IEC 61850 Environment)
As a coordination center in the automation control system, it interfaces and links with SCADA, HMI, and communication gateway.
Power grid protection and automatic switching system
Used for managing key operations such as circuit breaker tripping and closing, bus switching, power conversion, etc.
Automatic protection system for power plants and industrial substations
Applied to critical energy and industrial infrastructure sites to ensure system safety and reliable operation.
