在机箱中安装MVME187注意，如果要将MVME187用作系统控制器，它必须安装在最左侧的卡插槽（插槽1）中，否则可能安装在任何未使用的双高卡槽。
表3-9。MVME187安装程序步进动作
1.将IACK和BG跳线从背板上拆下，用于安装MVME187将安装在中。
2小心地将MVME187滑入机箱前部的卡槽中。
❏ MVME187需要P1和P2供电。确保模块正确安装在背板。
❏ 不要损坏或弯曲连接器针脚。
TRICONEX 3604E工控卡件❏ 用提供的螺钉将MVME187固定在机箱中，与横向安装轨道良好接触，以尽量减少RFI排放。过渡模块和适配器板概述MVME187支持MVME712-12、MVME712-13、，MVME712M、MVME712A、MVME712AM和MVME712B过渡模块（本手册中称为MVME712X，除非另有规定）。注意：系统中的其他模块可能必须移动到为具有双宽前面板的MVME712M留出空间。MVME712X转换模块提供配置头和用于内部和外部输入/输出设备的行业标准连接器。MVME187上的输入/输出连接到VMEbus P2连接器。
❏ MVME712X转换模块连接到MVME187直通电缆和P2适配器板，如图所示在第3-18页的图3-2中。注：MVME712X未提供一些电缆因此必须由用户。（摩托罗拉建议使用屏蔽电缆将所有与外围设备的连接最小化辐射。）
Installing the MVME187 in the Chassis
Note that if the MVME187 is to be used as system controller, it must
installed in the left-most card slot (slot 1), otherwise it may be installed in
any unused double-height card slot.
Table 3-9. MVME187 Installation Procedure
Step Action
1 Remove IACK and BG jumpers from backplane for the card slot that the
MVME187 is to be installed in.
2 Carefully slide the MVME187 into the card slot in the front of the chassis.
❏ The MVME187 requires power from both P1 and P2. Be sure the
module is seated properly into the P1 and P2 connectors on the
backplane.
❏ Do not damage or bend connector pins.
❏ Fasten the MVME187 in the chassis with screws provided,
making good contact with the transverse mounting rails to
minimize RFI emissions. Transition Modules and Adapter Boards Overview
The MVME187 supports the MVME712-12, MVME712-13,
MVME712M, MVME712A, MVME712AM, and MVME712B
transition modules (referred to in this manual as MVME712X,
unless separately specified).
Note Other modules in the system may have to be moved to
allow space for the MVME712M which has a doublewide front panel.
MVME712X transition modules provide configuration headers and
industry-standard connectors for internal and external I/O devices.
The I/O on the MVME187 is connected to the VMEbus P2
connector.
❏ The MVME712X transition module is connected to the
MVME187 through cables and a P2 adapter board as shown
in Figure 3-2 on page 3-18.
Note Some cable(s) are not provided with the MVME712X
module(s), and therefore must be made or provided by
the user. (Motorola recommends using shielded cables
for all connections to peripherals to minimize
radiation.)
