MMS6823/9100-00001-05前置器,EPRO使用指导
并行端口接口PCCchip2提供8位双向并行端口。这端口可用作与Centronics兼容的并行打印机端口或作为通用并行输入/输出端口。
端口的所有八位必须是输入或输出（否单个位选择）。除了8位数据外，还有两个控制引脚和五个状态引脚。当用作并行打印机端口时，这些引脚的功能如下：每个状态引脚都可以在任何以下可编程条件之一：
❏ 高水平
❏ 低电平
❏ 高-低转换
❏ 低到高转换PCCCIP2提供了与MVME147 PCC。
❏ 在自动选通模式下，写入打印机数据寄存器后，PCCCip2自动为打印机快速选通控制位指定的选定时间。
MMS6823/9100-00001-05前置器❏ 在手动模式下，打印机直接选择控制位控制选通*引脚的状态。以太网接口
82596CA实现以太网收发器接口。这个82596CA使用DMA操作访问本地RAM以执行其正常功能。以太网收发器接口位于MVME187上，并且行业标准连接器位于MVME712X上过渡模块。
每个MVME187分配一个以太网站地址。这个地址是$08003E2xxxxx，其中xxxxx是唯一的5位字节分配给电路板的编号（即每个MVME187具有不同的xxxxx的值）。
每个模块的标签上都显示了以太网站地址连接到VMEbus P2连接器。此外，六个字节包括以太网地址存储在配置区域中BBRAM的。也就是说，08003E2xxxxx存储在BBRAM中。
❏ 在地址为$FFFC1F2C时，前四个字节（08003E2x）可以读取。
❏ 在地址为$FFFC1F30时，较低的两个字节（xxxx）可以被阅读。
MVME187调试器能够检索或设置以太网地址。
如果BBRAM中的数据丢失，用户应使用恢复VMEbus P2连接器标签。Summary
