TRICONEX EPI3382 通讯模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
型号：TRICONEX EPI3382
类型：通信接口模块（Enhanced Performance Interface, EPI）
产品概述
TRICONEX EPI3382 是一款增强型通信模块，主要用于 Triconex 安全控制系统与上位机或第三方系统之间的高速数据通信。该模块支持多种工业通信协议，并具备高性能处理能力和三重冗余同步功能，是分布式控制系统（DCS）、SCADA、历史数据库等系统与 Tricon 控制器之间通信的桥梁。
主要功能
实现 Tricon 控制器与外部系统间的数据交换
支持多个通信端口并行工作
可进行多协议数据封装和格式转换
提供网络隔离和故障冗余转移能力
支持冗余对等通信模块协同运行，提高系统稳定性
技术参数
通信端口：最多支持 2 个 10/100 Mbps Ethernet 端口
协议支持（根据配置）：
Modbus TCP/IP
Modbus RTU/ASCII（需适配）
TCP/UDP 定制协议
OPC（通过服务器）
内部处理器：高性能嵌入式处理器，专用于数据通信任务
系统集成：可与 Tricon 系统主控架构配套使用，通过系统背板通信
模块地址识别：自动识别与配置，无需人工跳线
状态指示：面板带有通信状态和模块状态 LED 指示灯
热插拔功能：支持在线插拔更换模块
英文资料：
Model: TRICONEX EPI3382
Type: Enhanced Performance Interface (EPI) communication interface module
product overview
The Triconex EPI3382 is an enhanced communication module primarily used for high-speed data communication between Triconex safety control systems and host computers or third-party systems. This module supports multiple industrial communication protocols and has high-performance processing capabilities and triple redundancy synchronization functions. It serves as a bridge for communication between distributed control systems (DCS), SCADA, historical databases, and Tricon controllers.
major function
Realize data exchange between Tricon controller and external systems
Support parallel operation of multiple communication ports
Capable of multi protocol data encapsulation and format conversion
Provide network isolation and fault redundancy transfer capability
Support collaborative operation of redundant peer-to-peer communication modules to improve system stability
Technical Parameter
Communication ports: Supports up to 2 10/100 Mbps Ethernet ports
Protocol support (based on configuration):
Modbus TCP/IP
Modbus RTU/ASCII (adaptation required)
TCP/UDP custom protocol
OPC (via server)
Internal processor: High performance embedded processor dedicated to data communication tasks
System integration: It can be used in conjunction with the main control architecture of the Tricon system and communicates through the system backplane
Module address recognition: automatic recognition and configuration, no need for manual jumpers
Status indication: The panel is equipped with communication status and module status LED indicators
Hot swappable function: supports online plugging and swapping of modules
2.产 品 展 示
