TRICONEX DO2401 7400209-030 数字输出底座 PDF资料
1.产 品 资 料 介 绍：
中文资料：
型号：TRICONEX DO2401
部件号：7400209-030
类型：数字输出底座模块（Digital Output Baseplate）
产品定位
DO2401 是 Triconex 系统中用于数字输出信号连接的底座模块，专为 DO3401 等数字输出模块提供硬件连接接口。它通过接线端子将控制系统的输出信号传送至现场设备，如继电器、电磁阀、接触器等。
核心作用
为 DO3401 数字输出模块提供物理安装接口和现场接线端子
实现模块与外部负载（如电磁阀、继电器等）的连接
提供输出通道的电气隔离与故障保护
有助于维护和更换输出模块时实现无缝对接
技术参数
适配模块：TRICONEX DO3401 数字输出模块
通道数量：32 个数字输出通道（每通道独立）
输出电压：24 VDC（外部供电）
负载类型：适用于感性负载或阻性负载
安装方式：DIN 导轨或机架安装
接线方式：螺丝压接式端子（每通道独立接线）
隔离设计：输出通道与系统总线电气隔离，增强抗干扰性能
保护功能：具备过流保护、短路保护、接地故障保护等
模块特点
高可靠性：适配 Tricon 三重冗余控制系统，支持高可用性要求。
结构简洁：模块化设计，便于安装与维护。
状态显示：部分版本支持 LED 指示灯显示通道输出状态（需配合上层模块）
热插拔支持：支持模块在线更换，不中断系统运行。
抗干扰能力强：电气隔离保护，适用于电磁环境复杂的工业现场。
英文资料：
Model: TRICONEX DO2401
Part number: 7400209-030
Type: Digital Output Baseplate Module
product positioning
DO2401 is a base module used for digital output signal connection in the Triconex system, specifically designed to provide hardware connection interfaces for digital output modules such as DO3401. It transmits the output signals of the control system to on-site devices such as relays, solenoid valves, contactors, etc. through wiring terminals.
central role
Provide physical installation interface and on-site wiring terminals for DO3401 digital output module
Connect the module to external loads such as solenoid valves, relays, etc
Provide electrical isolation and fault protection for output channels
Helps achieve seamless integration when maintaining and replacing output modules
Technical Parameter
Adaptation module: Triconex DO3401 digital output module
Number of channels: 32 digital output channels (each channel is independent)
Output voltage: 24 VDC (external power supply)
Load type: Suitable for inductive or resistive loads
Installation method: DIN rail or rack installation
Wiring method: Screw crimping terminal (independent wiring for each channel)
Isolation design: The output channel is electrically isolated from the system bus to enhance anti-interference performance
Protection function: equipped with overcurrent protection, short circuit protection, ground fault protection, etc
Module Features
High reliability: compatible with Tricon triple redundant control system, supporting high availability requirements.
Simple structure: modular design, easy to install and maintain.
Status display: Some versions support LED indicator lights to display channel output status (requires coordination with upper level modules)
Hot swappable support: Supports online module replacement without interrupting system operation.
Strong anti-interference ability: Electrical isolation protection, suitable for industrial sites with complex electromagnetic environments.
2.产 品 展 示
