GE IS220PDIAH1A 独立模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
IS220PDIAH1A 是 Mark VIe 控制系统中的一个DIN 导轨安装型数字输入模块，用于采集工业现场的干接点或有源/无源开关信号。该模块支持多通道数字输入，每个通道独立隔离，并通过 IONet 与主控系统（如控制器或 I/O Pack）通信。
主要技术参数
| 项目 | 说明 |
|---|---|
| 模块类型 | 数字输入模块（PDI：Packaged Digital Input） |
| 输入通道数量 | 16 路隔离数字输入通道 |
| 输入电压范围 | 通常为 24V DC（逻辑“1”有效） |
| 通道绝缘 | 每通道隔离（与地和其他通道之间） |
| 通道状态LED指示 | 每个通道有对应指示灯显示通断状态 |
| 通讯接口 | IONet（支持 Ethernet 和通信冗余） |
| 安装方式 | DIN 导轨安装 |
| 电源供应 | 通过连接到 I/O Pack 提供低压电源（约 28V DC） |
| 模块尺寸 | 紧凑型结构，适配标准控制柜空间 |
| 工作温度范围 | -30°C 至 +65°C |
| 电气安全与认证 | 满足 CE、UL、CSA、ATEX 等工业安全标准（视版本而定） |
16 路隔离数字输入：适用于检测干接点、继电器、开关等状态信号
模块热插拔：支持在线更换，无需断电，减少维护时间
LED 状态指示：便于现场诊断和通道状态查看
与 Mark VIe 控制器无缝集成：兼容所有 GE 控制网络配置
内置信号保护：具备过压、反接、浪涌等保护措施
支持冗余系统结构：可在双通道冗余架构中应用
英文资料：
IS220PDIAH1A is a DIN rail mounted digital input module in the Mark VIe control system, used to collect dry contact or active/passive switch signals from industrial sites. This module supports multi-channel digital inputs, with each channel independently isolated and communicating with the main control system (such as controllers or I/O packs) through IONet.
Main technical parameters
Project Description
Module Type: Digital Input Module (PDI: Packaged Digital Input)
Number of input channels: 16 isolated digital input channels
The input voltage range is usually 24V DC (logic "1" is valid)
Channel insulation isolates each channel (between ground and other channels)
Channel status LED indicates that each channel has a corresponding indicator light displaying the on/off status
Communication interface IONet (supporting Ethernet and communication redundancy)
Installation method: DIN rail installation
The power supply is connected to the I/O Pack to provide low-voltage power (approximately 28V DC)
Compact module size structure, suitable for standard control cabinet space
Working temperature range -30 ° C to+65 ° C
Electrical safety and certification meet industrial safety standards such as CE, UL, CSA, ATEX (depending on version)
Product Features
16 isolated digital inputs: suitable for detecting status signals of dry contacts, relays, switches, etc
Module hot swappable: supports online replacement without power outage, reducing maintenance time
LED status indicator: convenient for on-site diagnosis and channel status viewing
Seamless integration with Mark VIe controller: compatible with all GE control network configurations
Built in signal protection: equipped with overvoltage, reverse connection, surge and other protection measures
Support redundant system architecture: can be applied in dual channel redundant architecture
