ABB 3BHE014070R0101 驱动控制板 PDF资料
1.产 品 资 料 介 绍：
中文资料：
ABB 3BHE014070R0101 驱动控制板是 ABB 变频器系统中的一个关键组件，专门用于控制和调节驱动系统的各种参数。它通常被用于 ABB 的高压或中压驱动系统，负责对电机的控制、信号处理和保护。此控制板具备实时监控电机和变频器的运行状态，以及执行电流、电压、频率等控制指令的功能。
主要功能
电机控制：精确控制电机的启动、停机、转速调节等。
逆变器调制：驱动逆变器模块，通过 PWM（脉宽调制）控制信号实现高效电能转换。
故障诊断：具有自诊断功能，能够实时监测电压、电流、温度等关键参数并触发警报。
系统保护：提供电流过载、过温、短路等保护功能。
通讯接口：支持与 ABB 控制系统或其他外部设备的通讯，包括 RS-485 或专用总线接口。
信号采样和处理：实时采集电压、电流等信号并进行处理，确保系统的精准控制。
应用领域
工业自动化：用于各种工业自动化设备和驱动控制系统。
电力和能源：适用于风机、水泵、压缩机等高压电机驱动控制系统。
石化与冶金：在高压驱动控制中应用广泛。
冶金、电力、采矿等行业：可以用于这些领域的电机控制和驱动管理。
典型硬件参数
供电电压：由主控单元或电源模块提供（例如5V、15V）。
通信接口：常见的接口包括 RS-485、CAN 总线等。
工作温度范围：通常为 0°C 至 60°C。
存储温度范围：-40°C 至 85°C。
板卡结构：多层电路板，通常具有防护涂层以防止环境干扰。
兼容系统
此驱动控制板一般与以下设备一起使用：
ABB ACS 系列变频器（例如 ACS5000、ACS6000）。
ABB DCS（分布式控制系统）。
ABB 高压和中压变频驱动系统。
英文资料：
The ABB 3BHE014070R0101 drive control board is a key component in the ABB inverter system, specifically designed to control and regulate various parameters of the drive system. It is commonly used in ABB's high or medium voltage drive systems, responsible for controlling, signal processing, and protecting motors. This control board has the function of real-time monitoring of the operating status of motors and frequency converters, as well as executing control commands such as current, voltage, and frequency.
major function
Motor control: precise control of motor start, stop, speed adjustment, etc.
Inverter modulation: Drive the inverter module to achieve efficient energy conversion through PWM (pulse width modulation) control signals.
Fault diagnosis: With self diagnostic function, it can monitor key parameters such as voltage, current, temperature in real time and trigger alarms.
System protection: Provides protection functions such as current overload, over temperature, and short circuit.
Communication interface: Supports communication with ABB control systems or other external devices, including RS-485 or dedicated bus interfaces.
Signal sampling and processing: Real time acquisition and processing of voltage, current, and other signals to ensure precise control of the system.
application area
Industrial automation: used for various industrial automation equipment and drive control systems.
Electricity and Energy: Suitable for high-voltage motor drive control systems such as fans, pumps, compressors, etc.
Petrochemicals and Metallurgy: Widely used in high-pressure drive control.
Metallurgy, power, mining and other industries: can be used for motor control and drive management in these fields.
Typical hardware parameters
Power supply voltage: provided by the main control unit or power module (e.g. 5V, 15V).
Communication interface: Common interfaces include RS-485, CAN bus, etc.
Working temperature range: usually from 0 ° C to 60 ° C.
Storage temperature range: -40 ° C to 85 ° C.
Board structure: Multi layer circuit board, usually with protective coating to prevent environmental interference.
Compatible system
This drive control board is generally used with the following devices:
ABB ACS series frequency converters (such as ACS5000, ACS6000).
ABB DCS (Distributed Control System).
ABB high-voltage and medium voltage variable frequency drive systems.
