TRICONEX MP3101 主处理器模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
TRICONEX MP3101 是一款三重冗余安全控制系统主处理器模块，作为整个 Tricon 系统的中央控制单元，负责处理 I/O 模块数据、执行用户逻辑程序、系统通信管理和故障诊断等任务。该模块专为满足高安全等级（如 SIL3）设计。
【关键技术参数】
| 项目 | 参数说明 |
|---|---|
| 处理器架构 | 三重冗余（Triple Modular Redundancy, TMR） |
| 冗余类型 | 三路独立 CPU 通道、三路运行状态比较器 |
| 执行速度 | 高速并行处理，确保低延迟高可靠响应 |
| 用户逻辑程序支持 | 支持 IEC 61131-3 标准语言（LD、FBD、ST、SFC） |
| 内存容量 | 多级程序和数据存储（详见用户手册），支持用户应用和诊断存储 |
| 软件支持 | TriStation 1131（用于编程、仿真、配置、诊断） |
| 系统同步 | 支持多个 MP3101 之间主控同步（用于冗余控制或扩展系统） |
| 通信功能 | 与所有 I/O 模块通信并可通过通讯模块接入 DCS/SCADA 等系统 |
| 冗余支持 | 主处理器模块可配置为主用、备用，自动切换保障连续运行 |
| 安装方式 | 插入 Tricon 系统标准机架槽位 |
| 在线热插拔 | 支持（在系统运行中更换无需断电） |
【环境适应性】
工作温度范围：0～60°C
储存温度范围：-40～85°C
抗震抗干扰能力：符合工业电气设备国际标准
湿度范围：5–95%（无凝结）
英文资料：
The TriconeX MP3101 is a triple redundant safety control system main processor module that serves as the central control unit of the entire Tricon system, responsible for processing I/O module data, executing user logic programs, system communication management, and fault diagnosis tasks. This module is designed specifically to meet high security levels such as SIL3.
[Key Technical Parameters]
Project parameter description
Triple Modular Redundancy (TMR) in processor architecture
Redundant type with three independent CPU channels and three running status comparators
High speed parallel processing ensures low latency and high reliability response
User logic program supports IEC 61131-3 standard languages (LD, FBD, ST, SFC)
Multi level program and data storage with memory capacity (see user manual for details), supporting user applications and diagnostic storage
Software supports TriStation 1131 (for programming, simulation, configuration, diagnosis)
System synchronization supports main control synchronization between multiple MP3101 (for redundant control or system expansion)
The communication function communicates with all I/O modules and can be connected to DCS/SCADA and other systems through the communication module
Redundant support: The main processor module can be configured as primary or backup, with automatic switching to ensure continuous operation
Installation method: Insert into the standard rack slot of the Tricon system
Online hot swappable support (replacement during system operation without power outage)
Environmental adaptability
Working temperature range: 0-60 ° C
Storage temperature range: -40 to 85 ° C
Seismic and anti-interference capability: compliant with international standards for industrial electrical equipment
Humidity range: 5-95% (no condensation)
