GE 193X711AEG03功率放大器卡 PDF资料
1.产 品 资 料 介 绍：
中文资料：
一、产品概述
193X711AEG03 是由美国 GE（通用电气）公司生产的 193X 系列工业控制模块之一，专用于电机驱动系统中的功率放大控制。该卡通常部署于大型工业驱动或发电设备中，用于提供驱动所需的放大控制电流或电压信号。
二、主要功能
信号放大：将控制板或调节板输出的低电平信号进行电压或电流放大，满足驱动模块所需功率等级。
驱动接口：向主功率模块（如可控硅整流器或逆变器）提供触发信号。
保护功能：具备基本的电流限制、过温保护、输出限幅等功能。
信号隔离：输入与输出回路之间具备光电或磁隔离，提高系统抗干扰能力。
闭环反馈支持：可与外部速度、电流、电压传感器配合，构成闭环控制系统。
三、技术参数（典型值，仅供参考）
供电电压：+5V、±15V DC（来自系统母板）
输入信号类型：模拟电压信号（如 0–10V）、数字触发信号等
输出电流能力：驱动大功率器件的控制级电流（数十至数百 mA）
信号增益：固定或可调（依模块设定）
接口类型：边缘连接器，插入式安装
冷却方式：依靠系统风冷，部分型号配散热器
工作温度：-10°C ～ +60°C
尺寸规格：193X 系列标准卡件尺寸
四、应用领域
工业电机控制系统（直流调速或变频驱动）
GE Mark II/Mark IV 汽轮机控制系统
大型风机、水泵控制中心
电力设备调压控制
自动化生产线主驱动装置控制部分
英文资料：
1、 Product Overview
193X711AEG03 is one of the 193X series industrial control modules produced by General Electric in the United States, specifically designed for power amplification control in motor drive systems. This card is often deployed in large industrial drives or power generation equipment to provide amplified control current or voltage signals required for driving.
2、 Main functions
Signal amplification: Amplify the low-level signal output by the control board or regulating board with voltage or current to meet the required power level of the driving module.
Drive interface: Provide trigger signals to the main power module (such as thyristor rectifier or inverter).
Protection function: It has basic functions such as current limiting, over temperature protection, and output limiting.
Signal isolation: There is photoelectric or magnetic isolation between the input and output circuits to improve the system's anti-interference ability.
Closed loop feedback support: It can be combined with external speed, current, and voltage sensors to form a closed-loop control system.
3、 Technical parameters (typical values, for reference only)
Power supply voltage:+5V, ± 15V DC (from the system motherboard)
Input signal type: analog voltage signal (such as 0-10V), digital trigger signal, etc
Output current capability: Control level current for driving high-power devices (tens to hundreds of mA)
Signal gain: fixed or adjustable (depending on module settings)
Interface type: Edge connector, plug-in installation
Cooling method: relying on system air cooling, some models are equipped with radiators
Working temperature: -10 ° C to+60 ° C
Size specification: 193X series standard card size
4、 Application Fields
Industrial motor control system (DC speed regulation or variable frequency drive)
GE Mark II/Mark IV Turbine Control System
Large scale fan and water pump control center
Voltage regulation control of power equipment
Main drive device control part of automated production line
2.产 品 展 示
