GE 193X708AAG02发电机板 PDF资料
1.产 品 资 料 介 绍：
中文资料：
GE 193X708AAG02 发电机板技术资料
产品型号：193X708AAG02
产品名称：发电机板（Generator Control Board）
制造商：General Electric (GE)
系列：193X 系列工业控制板卡
功能分类：发电机控制与保护模块（Generator Control and Protection）
应用领域：发电机组控制、发电厂自动化、能源管理系统等
一、产品功能
GE 193X708AAG02 发电机板主要用于发电机的自动控制、调节以及保护。在发电机系统中，它提供了对电压、频率、功率等参数的实时控制和调节，并能够实现对设备的故障检测和保护。该板卡通过与发电机控制系统的紧密协作，确保发电机的稳定运行，并在出现异常情况下进行及时报警和停机保护，防止设备损坏。
主要功能：
电压调节：通过对发电机输出电压的实时调节，确保电力系统的稳定性。
频率控制：调节发电机的转速和输出频率，以符合电网要求。
功率调节：根据负载需求调节发电机的输出功率，确保发电机高效运行。
发电机保护：实时监控发电机的运行状态，包括温度、电流、电压等参数，提供过载、过热、短路等保护。
远程监控：支持与远程监控系统连接，便于集中监控多个发电机组的运行状态。
报警与故障诊断：当发电机出现故障或工作状态异常时，自动报警并进行故障诊断。
二、主要技术参数
| 参数项 | 说明描述 |
|---|---|
| 控制功能 | 自动电压调节、频率控制、功率调节 |
| 输入信号类型 | 电流、电压、温度等模拟信号输入 |
| 输出信号类型 | 电压、电流、频率等控制信号输出 |
| 保护功能 | 过载保护、短路保护、过温保护、低频率/高频率保护等 |
| 工作电压范围 | 适用的输入电压范围一般为 24V DC 或 48V DC（具体视系统要求而定） |
| 电气隔离 | 提供输入与输出之间的电气隔离，防止电气干扰 |
| 工作温度范围 | -40°C 到 +85°C，适应各种工业环境 |
| 卡片尺寸 | 标准 GE 插卡式模块尺寸，符合 193X 系列格式 |
| 安装方式 | 插卡式，适配 GE 193X 系列控制机架 |
| 通讯接口 | 支持多种工业通讯协议，如 Modbus、Profibus 等 |
| 故障诊断功能 | 内置故障记录与报警功能，支持故障代码诊断 |
英文资料：
GE 193X708AAG02 Generator Board Technical Data
Product model: 193X708AAG02
Product Name: Generator Control Board
Manufacturer: General Electric (GE)
Series: 193X series industrial control board
Function classification: Generator Control and Protection Module
Application areas: generator control, power plant automation, energy management systems, etc
1、 Product Features
The GE 193X708AAG02 generator board is mainly used for automatic control, regulation, and protection of generators. In the generator system, it provides real-time control and regulation of parameters such as voltage, frequency, and power, and can achieve fault detection and protection of equipment. This board ensures the stable operation of the generator through close cooperation with the generator control system, and provides timely alarm and shutdown protection in case of abnormal situations to prevent equipment damage.
Main functions:
Voltage regulation: By real-time adjustment of the output voltage of the generator, the stability of the power system is ensured.
Frequency control: Adjust the speed and output frequency of the generator to meet the requirements of the power grid.
Power regulation: Adjust the output power of the generator according to the load demand to ensure efficient operation of the generator.
Generator protection: Real time monitoring of the operating status of the generator, including parameters such as temperature, current, voltage, etc., providing protection against overload, overheating, short circuit, etc.
Remote monitoring: Supports connection with remote monitoring systems for centralized monitoring of the operating status of multiple generator sets.
Alarm and fault diagnosis: When the generator malfunctions or has abnormal working conditions, it will automatically alarm and perform fault diagnosis.
2、 Main technical parameters
Parameter item description
Control functions include automatic voltage regulation, frequency control, and power regulation
Input signal type: Analog signal input such as current, voltage, temperature, etc
Output signal type: Voltage, current, frequency, etc. Control signal output
Protection functions include overload protection, short circuit protection, over temperature protection, low-frequency/high-frequency protection, etc
The applicable input voltage range for the working voltage range is generally 24V DC or 48V DC (depending on system requirements)
Electrical isolation provides electrical isolation between input and output to prevent electrical interference
Working temperature range -40 ° C to+85 ° C, suitable for various industrial environments
Card size standard GE plug-in card module size, in accordance with the 193X series format
Installation method: plug-in card, compatible with GE 193X series control rack
The communication interface supports multiple industrial communication protocols, such as Modbus, Profibus, etc
The fault diagnosis function has built-in fault recording and alarm functions, supporting fault code diagnosis
