GE 193X706AAG01缓冲放大器卡 PDF资料
1.产 品 资 料 介 绍：
中文资料：
GE 193X706AAG01 缓冲放大器卡技术资料
产品型号：193X706AAG01
产品名称：缓冲放大器卡（Buffer Amplifier Card）
制造商：General Electric (GE)
系列：193X 系列控制板卡
功能分类：信号缓冲与放大模块（Signal Buffering and Amplification）
应用领域：工业控制、数据采集与处理系统
一、功能说明
GE 193X706AAG01 缓冲放大器卡是一种专为 GE 工业自动化系统设计的信号处理模块。它的主要功能是增强、放大输入信号，使其满足系统的输入要求，并且提供信号缓冲以确保稳定的信号传递。该卡广泛应用于需要信号增益或缓冲的控制系统中，如 PLC 控制系统、工业驱动控制、过程控制等领域。
二、主要技术参数
| 参数项 | 说明描述 |
|---|---|
| 输入信号类型 | 模拟信号（如电压、电流信号），常见为 0-10V、4-20mA 等 |
| 输出信号类型 | 放大后的模拟信号，通常为 0-10V 或其他标准电压/电流输出 |
| 放大增益 | 固定或可调增益，通常为 1x、10x、100x 等，具体依照卡的设计而定 |
| 信号隔离 | 具备输入与输出的电气隔离，防止信号干扰或高电压影响系统 |
| 供电电压 | ±15V DC 或 24V DC（依据系统供电标准） |
| 工作温度范围 | 通常为 -40°C 到 +85°C，适用于工业环境 |
| 连接方式 | 插卡式，适配 GE 193X 系列控制机架 |
| 卡片尺寸 | 标准 GE 插卡式模块尺寸，符合 193X 系列格式 |
| 输入/输出接口类型 | 通常为接线端子或插针接口，用于连接外部设备或传感器 |
英文资料：
GE 193X706AAG01 Buffer Amplifier Card Technical Data
Product model: 193X706AAG01
Product Name: Buffer Amplifier Card
Manufacturer: General Electric (GE)
Series: 193X series control board
Function classification: Signal Buffering and Amplification Module
Application areas: Industrial control, data acquisition and processing systems
1、 Function Description
The GE 193X706AAG01 buffer amplifier card is a signal processing module designed specifically for GE industrial automation systems. Its main function is to enhance and amplify input signals to meet the input requirements of the system, and provide signal buffering to ensure stable signal transmission. This card is widely used in control systems that require signal gain or buffering, such as PLC control systems, industrial drive control, process control, and other fields.
2、 Main technical parameters
Parameter item description
The input signal type is analog signal (such as voltage, current signal), commonly ranging from 0-10V, 4-20mA, etc
Output signal type: amplified analog signal, usually 0-10V or other standard voltage/current output
The amplification gain is fixed or adjustable, usually 1x, 10x, 100x, etc., depending on the design of the card
Signal isolation has electrical isolation between input and output to prevent signal interference or high voltage from affecting the system
Power supply voltage ± 15V DC or 24V DC (according to system power supply standards)
The working temperature range is usually -40 ° C to+85 ° C, suitable for industrial environments
Connection method plug-in card, compatible with GE 193X series control rack
Card size standard GE plug-in card module size, in accordance with the 193X series format
The input/output interface type is usually a terminal block or pin interface, used to connect external devices or sensors
