GE 193X643ABG110电源模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
GE 193X643ABG110 电源模块说明
GE 193X643ABG110 是通用电气（General Electric）193X 系列控制系统中的一款高可靠性电源模块（Power Supply Module），主要为控制系统中的多个电路板提供稳定的直流供电。该模块广泛应用于工业自动化系统、发电控制系统及大型机电设备中。
基本参数
型号：193X643ABG110
名称：电源模块 / Power Supply Module
制造商：General Electric (GE)
系列归属：GE 193X 系列控制系统模块
主要功能：为系统各控制模块提供多路稳定 DC 电源
典型输出电压：+5V、±15V、24V DC（视配置）
输入电压范围：85~264V AC 或 110V/220V AC（具体以铭牌为准）
频率范围：47~63Hz
最大输出功率：根据负载约为 50~150W
工作温度范围：-20°C ～ +70°C
安装方式：插槽式（标准193X卡件结构）
功能特点
多路输出：模块支持多个输出通道，分别供电给控制板、信号板、继电器板等。
稳压性能优异：具备电压稳压与负载调整功能，适应不同工况。
短路/过流/过压保护：输出端具备多重保护机制，防止损坏系统其他模块。
电磁干扰抑制：内置 EMI 滤波器，降低对周边设备干扰。
自诊断指示：带有LED状态指示灯，便于现场维护。
模块化结构：支持热插拔更换，方便检修与升级。
英文资料：
GE 193X643ABG110 Power Module Description
GE 193X643ABG110 is a high reliability power supply module in the General Electric 193X series control system, mainly providing stable DC power supply for multiple circuit boards in the control system. This module is widely used in industrial automation systems, power generation control systems, and large-scale electromechanical equipment.
Basic parameters
Model: 193X643ABG110
Name: Power Supply Module
Manufacturer: General Electric (GE)
Series affiliation: GE 193X series control system module
Main function: Provide multiple stable DC power sources for various control modules in the system
Typical output voltage:+5V, ± 15V, 24V DC (depending on configuration)
Input voltage range: 85-264V AC or 110V/220V AC (please refer to the nameplate for details)
Frequency range: 47~63Hz
Maximum output power: approximately 50~150W depending on the load
Working temperature range: -20 ° C to+70 ° C
Installation method: slot type (standard 193X card structure)
Functional Features
Multi channel output: The module supports multiple output channels, which supply power to the control board, signal board, relay board, etc.
Excellent voltage stabilization performance: equipped with voltage stabilization and load adjustment functions, suitable for different working conditions.
Short circuit/overcurrent/overvoltage protection: The output terminal has multiple protection mechanisms to prevent damage to other modules of the system.
Electromagnetic interference suppression: Built in EMI filter to reduce interference with surrounding devices.
Self diagnostic indicator: equipped with LED status indicator light for easy on-site maintenance.
Modular structure: supports hot swappable replacement, facilitating maintenance and upgrades.
