GE 193X278AAG03继电器板 PDF资料
1.产 品 资 料 介 绍：
中文资料：
GE 193X278AAG03 继电器板（Relay Board） 是 GE 193X 系列中用于工业控制系统的关键输出模块，主要功能是实现逻辑控制信号与高功率执行元件之间的电气隔离与联动控制。该模块被广泛用于电力系统、自动化控制系统和驱动系统中，用以控制马达、报警设备、断路器等执行单元。
一、产品基本信息
| 项目 | 内容 |
|---|---|
| 产品型号 | 193X278AAG03 |
| 产品名称 | 继电器板（Relay Board） |
| 制造商 | GE（General Electric） |
| 系列 | 193X 控制系统模块系列 |
| 安装方式 | 插卡式，安装于193X主控机架中 |
二、主要功能
| 功能模块 | 描述 |
|---|---|
| 继电器输出 | 接收来自控制逻辑（如PLC或检测模块）的信号，控制高压/高电流回路通断 |
| 信号隔离 | 提供控制电路与负载电路之间的电气隔离，保护核心控制器件 |
| 状态指示 | 一般带有LED或信号指示灯，显示继电器动作状态 |
| 多通道控制 | 支持多个独立通道控制（视版本而定），实现多点输出 |
| 过流保护 | 内建熔断或过载保护功能，防止异常电流损坏板卡 |
三、技术参数（典型）
| 参数类别 | 参数说明 |
|---|---|
| 控制电压 | 通常为5V DC 或 24V DC |
| 继电器类型 | 电磁继电器（DPDT 或 SPDT，具体以实物为准） |
| 输出容量 | 每通道可支持最高250V AC，5A负载（视规格而定） |
| 通道数 | 多通道设计（如4/8通道），具体型号决定 |
| 响应时间 | < 10ms（典型继电器响应速度） |
| 绝缘耐压 | 控制端与负载端间隔离耐压 ≥1500V |
| 工作环境 | 温度：-20°C ~ +60°C，湿度：＜95%，无凝露 |
英文资料：
The GE 193X278AAG03 Relay Board is a key output module used in industrial control systems in the GE 193X series. Its main function is to achieve electrical isolation and linkage control between logic control signals and high-power execution components. This module is widely used in power systems, automation control systems, and drive systems to control execution units such as motors, alarm devices, circuit breakers, etc.
1、 Basic Product Information
Project Content
Product model 193X278AAG03
Product Name: Relay Board
Manufacturer GE (General Electric)
Series 193X Control System Module Series
Installation method: plug-in card, installed in the 193X main control rack
2、 Main functions
Function module description
Relay output receives signals from control logic (such as PLC or detection module) to control the on/off of high voltage/high current circuits
Signal isolation provides electrical isolation between control circuits and load circuits, protecting core control devices
The status indicator generally has LED or signal indicator lights to display the relay action status
Multi channel control supports multiple independent channel controls (depending on the version) to achieve multi-point output
The overcurrent protection has built-in fuse or overload protection function to prevent abnormal current from damaging the board
3、 Technical parameters (typical)
Parameter Category Parameter Description
The control voltage is usually 5V DC or 24V DC
Relay type: Electromagnetic relay (DPDT or SPDT, subject to actual product)
Output capacity: Each channel can support up to 250V AC, 5A load (depending on specifications)
Number of channels: Multi channel design (such as 4/8 channels), specific model to be determined
Response time<10ms (typical relay response speed)
Isolation withstand voltage between insulation withstand voltage control terminal and load terminal ≥ 1500V
Working environment temperature:- 20 ° C~+60 ° C, humidity:<95%, no condensation
2.产 品 展 示
