GE 193X256ABG01放大器 PDF资料
1.产 品 资 料 介 绍：
中文资料：
GE 193X256ABG01 放大器模块 是 GE（General Electric）193X 系列控制系统中的一款功能性电子电路板，常用于 GE 驱动控制系统或电机调速装置中。这是一种模拟信号放大器板，主要用于工业驱动系统中的信号放大、调节和隔离处理。
产品概述：
产品型号：193X256ABG01
制造商：GE Industrial Systems
产品类型：放大器电路板（Amplifier Board）
主要功能：模拟信号放大、滤波、驱动控制信号增强
主要功能与技术作用：
信号放大功能
用于对传感器或前级电路传输来的微弱电压、电流信号进行放大，便于后级控制电路识别与处理，常见于电流检测、电压反馈、速度反馈等控制环节。信号调节与隔离
具备滤波功能以抑制干扰，提升信号稳定性，同时实现模拟信号与主控系统间的隔离，增强系统可靠性。驱动控制支持
放大后的信号可直接驱动继电器、可控硅、变频器等执行器件，在 GE 调速驱动系统中起到信号桥接和指令增强的作用。
典型应用场景：
工业变频调速系统：用于放大转速、电流等反馈信号，配合闭环调速控制
发电厂励磁控制系统：增强励磁系统中的模拟信号，保证调节精度
大型工业马达驱动系统：提高控制信号功率以驱动执行部件
铁路电气牵引系统：用于提高信号稳定性，确保牵引系统安全运行
能源、石化、钢铁等重工业设备：在复杂工业场景中承担高可靠性信号放大任务
总结：
GE 193X256ABG01 是一款性能可靠、功能精确的工业模拟信号放大器模块，广泛应用于 GE 自动化控制系统中，特别适合电机驱动、励磁控制和闭环反馈控制场景。
英文资料：
The GE 193X256ABG01 amplifier module is a functional electronic circuit board in the GE (General Electric) 193X series control system, commonly used in GE drive control systems or motor speed control devices. This is an analog signal amplifier board mainly used for signal amplification, regulation, and isolation processing in industrial drive systems.
Product Overview:
Product model: 193X256ABG01
manufacturer: GE Industrial Systems
Product type: Amplifier Board
Main functions: Analog signal amplification, filtering, drive control signal enhancement
Main functions and technical roles:
Signal amplification function
Used to amplify weak voltage and current signals transmitted from sensors or front-end circuits, facilitating identification and processing by back-end control circuits. It is commonly used in control processes such as current detection, voltage feedback, and speed feedback.
Signal conditioning and isolation
Equipped with filtering function to suppress interference, improve signal stability, and achieve isolation between analog signals and the main control system, enhancing system reliability.
Drive control support
The amplified signal can directly drive actuators such as relays, thyristors, and frequency converters, playing a role in signal bridging and instruction enhancement in GE speed control drive systems.
Typical application scenarios:
Industrial variable frequency speed control system: used to amplify feedback signals such as speed and current, and cooperate with closed-loop speed control
Power plant excitation control system: Enhance the analog signal in the excitation system to ensure regulation accuracy
Large industrial motor drive system: increasing control signal power to drive executing components
Railway electrical traction system: used to improve signal stability and ensure safe operation of the traction system
Heavy industry equipment such as energy, petrochemical, and steel: undertaking high reliability signal amplification tasks in complex industrial scenarios
Summary:
GE 193X256ABG01 is a reliable and precise industrial analog signal amplifier module widely used in GE automation control systems, particularly suitable for motor drive, excitation control, and closed-loop feedback control scenarios.
