ALCATEL LUCENT 695-5731-006电源模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
ALCATEL LUCENT 695-5731-006 电源模块
产品类型
通信设备专用电源模块（Power Supply Module for Telecom Systems）
产品描述
695-5731-006 是 Alcatel-Lucent 公司用于其通信系统中的专用电源模块，通常应用于大型交换设备、光接入设备或传输系统中，作为整个机架或子系统的电力核心。该模块负责为系统中的主控板、接口板及其他功能模块提供稳定的直流电压输出，保障设备长时间稳定运行。
该模块具有冗余配置能力、宽电压输入支持及输出稳压控制等特性，符合电信行业对高可靠性和高可用性的要求。
核心功能
电能转换：将输入的交流或直流电压转换为设备所需的多路直流输出
电压稳压与滤波：输出电压稳定，低纹波，保护设备免受波动影响
负载监控：实时监测输出电流，提供过载、短路、过温保护
远程管理功能：支持状态监控与告警输出，方便远程维护
支持热插拔：在不断电状态下可插拔更换，提高系统可维护性
产品特点
高转换效率（通常 >85%），降低能耗
高可靠性设计，适应连续7×24小时运行需求
标准模块化尺寸，适配 Alcatel-Lucent 各类机架系统
支持冗余备份，提高系统可靠性与容错能力
配有 LED 状态指示或通信接口，便于管理人员识别状态
典型应用领域
电信核心网络设备（如核心路由器、交换机）
光纤接入系统（如GPON/XGS-PON OLT设备）
传输系统（如SDH、WDM平台）
多业务接入平台（MSAP）
数据中心通信机柜供电系统
运营商远程局站设备电源系统
英文资料：
ALCATEL LUCENT 695-5731-006 power module
product type
Power Supply Module for Telecom Systems
product description
695-5731-006 is a dedicated power module used by Alcatel Lucent for its communication systems, typically used in large switching equipment, optical access equipment, or transmission systems as the power core for the entire rack or subsystem. This module is responsible for providing stable DC voltage output to the main control board, interface board, and other functional modules in the system, ensuring long-term stable operation of the equipment.
This module has the characteristics of redundant configuration capability, wide voltage input support, and output voltage stabilization control, which meets the requirements of the telecommunications industry for high reliability and high availability.
Core functions
Electric energy conversion: converting input AC or DC voltage into multiple DC outputs required by the equipment
Voltage stabilization and filtering: stable output voltage, low ripple, protecting equipment from fluctuations
Load monitoring: Real time monitoring of output current, providing overload, short circuit, and over temperature protection
Remote management function: supports status monitoring and alarm output, facilitating remote maintenance
Support hot plugging: can be plugged and replaced in a non powered state, improving system maintainability
Product Features
High conversion efficiency (usually>85%), reducing energy consumption
High reliability design, suitable for continuous 7 × 24-hour operation requirements
Standard modular size, compatible with various Alcatel Lucent rack systems
Support redundant backup to improve system reliability and fault tolerance
Equipped with LED status indicator or communication interface, making it easy for management personnel to identify the status
Typical application areas
Telecommunications core network equipment (such as core routers, switches)
Fiber optic access system (such as GPON/XGS-PON OLT equipment)
Transmission systems (such as SDH, WDM platforms)
Multi Service Access Platform (MSAP)
Power supply system for data center communication cabinet
Operator remote station equipment power system
2.产 品 展 示
