ALCATEL LUCENT 3HE03612AA端口模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
ALCATEL LUCENT 3HE03612AA 端口模块说明
一、产品概述
型号：3HE03612AA
名称：MDA-7750 20-PT GE MDA-XP-SFP
该模块是 Alcatel-Lucent 为其 7750 SR 系列高性能服务路由器设计的扩展端口模块，提供高密度的千兆以太网接入能力，广泛应用于运营商网络、企业网络和数据中心环境中。
二、技术参数
接口数量：20 个千兆以太网端口
接口类型：SFP 插槽（支持热插拔）
支持速率：1 Gbps（千兆）
模块类型：MDA（媒体依赖适配器）扩展模块
协议支持：以太网第二层（L2）交换功能，支持 VLAN、QoS 等网络功能
兼容平台：Alcatel-Lucent 7750 SR 系列服务路由器
三、应用领域
电信运营商核心网络
提供高密度 GE 接口，用于大容量业务承载与数据转发
应用于语音、视频、数据等多业务汇聚网络
城域网汇聚层
部署在接入层与核心层之间，完成大规模以太网流量整合
实现冗余备份、负载均衡和网络隔离功能
数据中心互联（DCI）
支持多种类型 SFP 光模块，满足不同距离连接要求
实现数据中心之间的高速光纤互联
大型企业园区网络
用于构建高带宽、低延迟的企业核心网络
满足大规模终端及服务器的并发接入需求
英文资料：
ALCATEL LUCENT 3HE03612AA Port Module Description
1、 Product Overview
Model: 3HE03612AA
name: MDA-7750 20-PT GE MDA-XP-SFP
This module is an expansion port module designed by Alcatel Lucent for its 7750 SR series high-performance service router, providing high-density Gigabit Ethernet access capability and widely used in operator networks, enterprise networks, and data center environments.
2、 Technical parameters
Number of interfaces: 20 Gigabit Ethernet ports
Interface type: SFP slot (supports hot swapping)
Supported speed: 1 Gbps (Gigabit)
Module type: MDA (Media Dependency Adapter) extension module
Protocol support: Ethernet Layer 2 (L2) switching function, supporting VLAN, QoS and other network functions
Compatible platform: Alcatel Lucent 7750 SR series service router
3、 Application Fields
Core network of telecommunications operators
Provide high-density GE interfaces for high-capacity business carrying and data forwarding
Applied to multi service aggregation networks such as voice, video, and data
Metropolitan Area Network Aggregation Layer
Deploy between the access layer and the core layer to complete large-scale Ethernet traffic integration
Implement redundant backup, load balancing, and network isolation functions
Data Center Interconnection (DCI)
Supports multiple types of SFP optical modules to meet different distance connection requirements
Realize high-speed fiber optic interconnection between data centers
Large enterprise park network
Used to build high bandwidth, low latency enterprise core networks
Meet the concurrent access requirements of large-scale terminals and servers
2.产 品 展 示
