HORNER ELECTRIC HE693RTD600J电动输入模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
HORNER ELECTRIC HE693RTD600J 是一款 电阻温度检测（RTD）输入模块，用于 GE Fanuc 90-30 PLC 系列，实现对温度信号的高精度测量。以下是该模块的详细信息：
主要特点：
兼容性
适用于 GE Fanuc 90-30 PLC，可直接插入 PLC 机架，作为温度采集模块使用。
输入通道
提供 6 个 RTD 传感器输入通道，支持多个 RTD 传感器的同时测量。
支持的 RTD 类型
100Ω 铂 RTD（Pt100）
120Ω 镍 RTD（Ni120）
10Ω 铜 RTD（Cu10）
兼容多种 RTD 传感器类型，包括：
测量范围
Pt100: -200°C ~ 850°C
Ni120: -80°C ~ 260°C
Cu10: -100°C ~ 260°C
分辨率与精度
分辨率：0.1°C
典型精度：±0.1% 满量程
信号处理与滤波
具有 自动冷端补偿，提高测量精度。
内置 噪声滤波功能，减少工业环境中的干扰。
通信与数据处理
采集的温度数据可以通过 PLC 逻辑程序 直接访问。
支持 模拟量数据转换，可用于工业控制系统的温度调节。
LED 指示灯
提供输入状态和故障指示，便于维护和诊断。
应用领域：
工业自动化（温度监测与控制）
食品加工（温度记录与调节）
HVAC 系统（供暖、通风、空调温度控制）
化工、冶金（过程温度监控）
英文资料：
HORNER ELECTRIC HE693RTD600J is a resistance temperature detection (RTD) input module used in the GE Fanuc 90-30 PLC series to achieve high-precision measurement of temperature signals. The following is the detailed information of the module:
Main features:
compatibility
Suitable for GE Fanuc 90-30 PLC, it can be directly inserted into the PLC rack and used as a temperature acquisition module.
Channel
Provide 6 input channels for RTD sensors, supporting simultaneous measurement of multiple RTD sensors.
Supported RTD types
Compatible with multiple types of RTD sensors, including:
100 Ω Platinum RTD (Pt100)
120 Ω Nickel RTD (Ni120)
10 Ω Copper RTD (Cu10)
measuring range
Pt100: -200°C ~ 850°C
Ni120: -80°C ~ 260°C
Cu10: -100°C ~ 260°C
Resolution and accuracy
Resolution: 0.1 ° C
Typical accuracy: ± 0.1% of full scale
Signal Processing and Filtering
Equipped with automatic cold end compensation to improve measurement accuracy.
Built in noise filtering function to reduce interference in industrial environments.
Communication and Data Processing
The collected temperature data can be directly accessed through the PLC logic program.
Supports analog data conversion and can be used for temperature regulation in industrial control systems.
LED indicator light
Provide input status and fault indication for easy maintenance and diagnosis.
Application areas:
Industrial Automation (Temperature Monitoring and Control)
Food processing (temperature recording and regulation)
HVAC system (heating, ventilation, air conditioning temperature control)
Chemical and metallurgical (process temperature monitoring)
