HORNER ELECTRIC HE693STP113步进器定位模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
HORNER ELECTRIC HE693STP113 是一款 步进器定位模块（Stepper Positioning Module），专为 GE Fanuc Series 90-30 PLC 设计，主要用于精确控制步进电机的运动，适用于自动化机械、数控加工、输送系统等应用。
HE693STP113 主要特性
高精度步进电机控制
通过脉冲和方向信号控制步进电机，实现精准定位。
兼容 GE Fanuc 90-30 PLC
无缝集成至 PLC 机架，支持 GE Fanuc PLC 编程与控制。
多种控制模式
点对点定位、速度控制、直线插补等多种运动控制模式，适应不同应用需求。
脉冲输出信号
可能支持 0-100kHz 脉冲输出，适用于不同规格的步进电机。
独立轴控制
允许 PLC 控制多个步进电机，支持多轴协同运动。
可编程加减速曲线
通过软件设定加速和减速斜率，优化运动平稳性。
工业级抗干扰能力
适用于复杂工业环境，确保长期稳定运行。
I/O 端口
可能集成输入输出端口，用于外部限位开关、急停信号等。
应用领域
CNC 数控机床：精确控制刀具进给，实现高精度加工。
自动化装配线：控制输送带步进电机，实现精准送料。
包装设备：控制封装、贴标、切割等精确运动。
机器人控制：用于步进电机驱动的机械手臂和自动化设备。
医疗设备：用于实验仪器的微量进样、精准旋转等运动控制。
英文资料：
HORNER ELECTRIC HE693STP113 is a stepper positioning module designed specifically for GE Fanuc Series 90-30 PLC. It is mainly used for precise control of stepper motor motion and is suitable for applications such as automation machinery, CNC machining, and conveyor systems.
HE693STP113 Main Features
High precision stepper motor control
By controlling the stepper motor with pulses and directional signals, precise positioning can be achieved.
Compatible with GE Fanuc 90-30 PLC
Seamless integration into PLC rack, supporting GE Fanuc PLC programming and control.
Multiple control modes
Multiple motion control modes such as point-to-point positioning, speed control, and linear interpolation are available to meet different application requirements.
Pulse output signal
May support 0-100kHz pulse output, suitable for stepper motors of different specifications.
Independent axis control
Allow PLC to control multiple stepper motors and support multi axis coordinated motion.
Programmable acceleration and deceleration curve
Optimize motion smoothness by setting acceleration and deceleration slopes through software.
Industrial grade anti-interference capability
Suitable for complex industrial environments, ensuring long-term stable operation.
I/O port
Possible integration of input and output ports for external limit switches, emergency stop signals, etc.
application area
CNC machine tool: precise control of tool feed to achieve high-precision machining.
Automated assembly line: Control the stepper motor of the conveyor belt to achieve precise feeding.
Packaging equipment: Control precise movements such as packaging, labeling, cutting, etc.
Robot control: used for stepper motor-driven robotic arms and automation equipment.
Medical equipment: used for motion control such as micro injection and precise rotation of experimental instruments.
2.产 品 展 示
