1.产 品 资 料 介 绍：
中文资料：
ABB CI860K01（3BSE032444R1） 是 AC 800M 控制系统中的通信接口模块，主要用于连接 FOUNDATION 现场总线 HSE（高速以太网）网络，以实现与现场设备的高效通信。
产品特点：
- FOUNDATION 现场总线支持：可将 AC 800M 控制器连接至 HSE 子网，实现可靠的现场总线通信。
- 冗余设计：支持冗余配置，提高系统可靠性和稳定性，每个 AC 800M 控制器最多可支持 12 个 CI860 模块。
- 模块化结构：便于安装、维护和系统扩展，适用于不同规模的自动化系统。
- 工业级可靠性：具备较强的抗干扰能力，能够在严苛的工业环境下稳定运行。
技术参数：
- 电源电压：24 VDC
- 功耗：2 W
- 通信速率：31.25 kbps 至 2 Mbps
- 工作温度：-25°C 至 70°C
- 尺寸：125 x 75 x 30 mm
- 重量：0.5 kg
应用领域：
- 石油和天然气：适用于管道监测、井口控制等。
- 化工行业：支持危险区域的自动化控制和数据采集。
- 电力系统：用于发电厂和变电站的过程控制。
- 水处理：支持污水处理、自来水厂等设施的远程监控。
该模块由处理器单元通过 CEX 总线供电，因此不需要额外的外部电源。在实际应用中，CI860K01 主要用于确保现场设备的数据能够高效、安全地传输到控制系统中。
英文资料：
ABB CI860K01 (3BSE032444R1) is a communication interface module in the AC 800M control system, mainly used to connect to the FOUNDATION fieldbus HSE (High Speed Ethernet) network to achieve efficient communication with field devices.
Product features:
FOUNDATION fieldbus support: The AC 800M controller can be connected to the HSE subnet to achieve reliable fieldbus communication.
Redundancy design: Supports redundant configuration, improves system reliability and stability, and each AC 800M controller can support up to 12 CI860 modules.
Modular structure: easy to install, maintain, and expand, suitable for automation systems of different scales.
Industrial grade reliability: It has strong anti-interference ability and can operate stably in harsh industrial environments.
Technical parameters:
Power supply voltage: 24 VDC
Power consumption: 2 W
Communication speed: 31.25 kbps to 2 Mbps
Working temperature:- 25 ° C to 70 ° C
Size: 125 x 75 x 30 mm
Weight: 0.5 kg
Application areas:
Oil and gas: suitable for pipeline monitoring, wellhead control, etc.
Chemical industry: supports automated control and data collection in hazardous areas.
Power system: used for process control in power plants and substations.
Water treatment: supports remote monitoring of facilities such as sewage treatment and water treatment plants.
This module is powered by the processor unit through the CEX bus, so no additional external power supply is required. In practical applications, CI860K01 is mainly used to ensure that data from on-site devices can be efficiently and securely transmitted to the control system.
2.产 品 展 示
