Bently 3500/91-02-00 190782-01 通信网关模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
Bently Nevada 3500/91-02-00（部件号：190782-01）是一款通信网关模块，专为3500系列机架提供数据通信功能，支持EGD（以太网全局数据）协议。该模块可用于将3500系统的状态和测量数据传输至其他控制系统，如DCS（分布式控制系统）或SCADA系统。
主要功能：
- 协议支持： 兼容EGD V2.01和以太网UDP/IP协议，实现高效数据传输。
- 以太网接口： 提供10BASE-T和100BASE-TX（双绞线）网络连接，符合IEEE 802.3标准。
- 数据交换： 支持生产者和消费者数据交换，包括机架状态、报警复位、报警抑制等功能。
- 系统兼容性： 可与支持EGD协议的控制系统（如GE Mark VIe）集成，实现状态监控和数据分析。
技术参数：
- 功耗： 典型功率7.4W。
- 安装方式：
- 主模块占用3500机架前部一个全高插槽。
- I/O模块安装于机架后部对应插槽。
- 前面板指示灯：
- OK指示灯： 显示模块运行状态。
- TX/RX指示灯： 指示网络通信情况。
应用场景：
- 电力行业： 用于发电厂设备监控，提高运行效率。
- 石油天然气： 实时监测旋转设备健康状况，防止设备故障。
- 工业自动化： 连接SCADA/DCS系统，实现远程监控和数据管理。
该模块可显著提高系统的监测能力，适用于对高可靠性和实时性要求较高的工业环境。
英文资料：
Bently Nevada 3500/91-02-00 (part number: 190782-01) is a communication gateway module designed to provide data communication functionality for 3500 series racks, supporting EGD (Ethernet Global Data) protocol. This module can be used to transmit the status and measurement data of the 3500 system to other control systems, such as DCS (Distributed Control System) or SCADA systems.
Main functions:
Protocol support: Compatible with EGD V2.01 and Ethernet UDP/IP protocols to achieve efficient data transmission.
Ethernet interface: Provides 10BASE-T and 100BASE-TX (twisted pair) network connections, compliant with IEEE 802.3 standard.
Data exchange: Supports data exchange between producers and consumers, including rack status, alarm reset, alarm suppression, and other functions.
System compatibility: It can be integrated with control systems that support EGD protocol (such as GE Mark VIe) to achieve status monitoring and data analysis.
Technical parameters:
Power consumption: Typical power of 7.4W.
Installation method:
The main module occupies a full height slot at the front of the 3500 rack.
The I/O module is installed in the corresponding slot at the rear of the rack.
Front panel indicator light:
OK indicator light: displays the operating status of the module.
TX/RX indicator light: Indicates network communication status.
Application scenarios:
Power industry: used for monitoring power plant equipment to improve operational efficiency.
Oil and gas: Real time monitoring of the health status of rotating equipment to prevent equipment failures.
Industrial automation: Connect SCADA/DCS systems to achieve remote monitoring and data management.
This module can significantly improve the monitoring capability of the system and is suitable for industrial environments that require high reliability and real-time performance.
