ABB IMHSS03 液压伺服模块器 PDF资料
1.产 品 资 料 介 绍：
中文资料：
ABB IMHSS03 是一款 液压伺服模块，用于精确控制液压系统中的执行器（如液压缸或液压马达）。它通常应用于 工业自动化、金属加工、塑料机械、机床控制和重载工业设备，实现高精度液压伺服控制。
1. 产品概述
- 制造商：ABB（Asea Brown Boveri）
- 产品型号：IMHSS03
- 产品类型：液压伺服控制模块（Hydraulic Servo Module）
- 应用领域：
- CNC 机床的液压驱动
- 注塑机、冲压机等液压控制设备
- 钢铁、造纸、能源等行业的液压伺服系统
- 其他精密液压控制应用
2. 技术参数
| 参数 | 规格 |
|---|---|
| 控制类型 | 液压伺服控制 |
| 输入电压 | 24V DC 或更高（根据系统配置） |
| 通信接口 | 可能支持 PROFIBUS、Modbus 或 CANopen（具体需参考型号说明） |
| 控制精度 | 高精度闭环液压控制 |
| 兼容性 | ABB PLC、DCS、运动控制系统 |
ABB IMHSS03 通过 电子伺服阀或比例阀 实现对液压系统的精准控制，具备高动态响应能力。
3. 主要功能
✅ 高精度液压控制：适用于复杂工业环境，实现压力、流量和位置的精准控制。
✅ 闭环反馈系统：结合液压传感器（如压力传感器、位移传感器）优化控制精度。
✅ 模块化设计：支持快速安装、更换，适用于不同液压系统。
✅ 智能诊断与保护：具备故障报警、过载保护、压力异常检测等功能。
✅ 兼容性强：可集成至 ABB PLC、DCS 或工业控制系统 中。
英文资料：
ABB IMHSS03 is a hydraulic servo module used for precise control of actuators in hydraulic systems, such as hydraulic cylinders or hydraulic motors. It is commonly used in industrial automation, metal processing, plastic machinery, machine tool control, and heavy-duty industrial equipment to achieve high-precision hydraulic servo control.
1. Product Overview
manufacturer: ABB（Asea Brown Boveri）
Product model: IMHSS03
Product type: Hydraulic Servo Module
Application areas:
Hydraulic Drive for CNC Machine Tools
Hydraulic control equipment such as injection molding machines and stamping machines
Hydraulic servo systems for industries such as steel, papermaking, and energy
Other precision hydraulic control applications
2. Technical parameters
Parameter specifications
Control type: Hydraulic servo control
Input voltage 24V DC or higher (depending on system configuration)
The communication interface may support PROFIBUS, Modbus, or CANopen (please refer to the model description for details)
High precision closed-loop hydraulic control with high control accuracy
Compatibility with ABB PLC DCS、 Motion control system
ABB IMHSS03 achieves precise control of hydraulic systems through electronic servo valves or proportional valves, with high dynamic response capability.
3. Main functions
✅ High precision hydraulic control: suitable for complex industrial environments, achieving precise control of pressure, flow rate, and position.
✅ Closed loop feedback system: Combining hydraulic sensors (such as pressure sensors and displacement sensors) to optimize control accuracy.
✅ Modular design: supports quick installation and replacement, suitable for different hydraulic systems.
✅ Intelligent diagnosis and protection: equipped with functions such as fault alarm, overload protection, and pressure anomaly detection.
✅ Strong compatibility: can be integrated into ABB PLC, DCS or industrial control systems.
2.产 品 展 示
