ABB 1SAJ520000R0101 UMC100-FBP.0 A4 电机控制器 PDF资料
1.产 品 资 料 介 绍：
中文资料：
ABB 1SAJ520000R0101 UMC100-FBP.0 A4 电机控制器 是一款高度灵活且功能强大的通用电机控制器。它用于保护和控制低压电机，并通过先进的通信接口实现集成化管理，广泛应用于工业自动化、电机保护和控制领域。
产品概述
主要功能：
- 提供电机保护（如过载保护、短路保护、接地故障保护等）。
- 支持对电机启动、运行、监控和停止进行全面控制。
- 集成通信功能，可与工业现场总线系统连接。
应用领域：
- 工业自动化生产线的电机控制与保护。
- 泵、风机和压缩机等设备的运行管理。
- 配电柜和控制柜中的电机监控与控制。
技术参数
| 参数 | 描述 |
|---|---|
| 型号 | 1SAJ520000R0101 UMC100-FBP.0 A4 |
| 额定电压 | 24-240 V AC/DC |
| 电流范围 | 0.24 A 至 63 A |
| 工作温度 | -25°C 至 +70°C |
| 通信接口 | FieldBusPlug（FBP）通信接口 |
| 支持协议 | Modbus、Profibus、Profinet、DeviceNet 等 |
| 安装方式 | DIN 导轨安装 |
| 输入输出 | 多达 6 个数字输入，3 个数字输出 |
| 保护功能 | 过载保护、短路保护、接地故障保护、堵转保护 |
| 显示方式 | 状态 LED 或外接 HMI 显示 |
| 防护等级 | IP20 |
英文资料：
The ABB 1SAJ520000R0101 UMC100-FBP. 0 A4 motor controller is a highly flexible and powerful universal motor controller. It is used to protect and control low-voltage motors, and achieves integrated management through advanced communication interfaces, widely used in industrial automation, motor protection, and control fields.
Product Overview
Main functions:
Provide motor protection (such as overload protection, short circuit protection, ground fault protection, etc.).
Support comprehensive control of motor start, operation, monitoring, and stop.
Integrated communication function, capable of connecting with industrial fieldbus systems.
Application areas:
Motor control and protection for industrial automation production lines.
Operation and management of equipment such as pumps, fans, and compressors.
Motor monitoring and control in distribution cabinets and control cabinets.
technical parameter
Parameter description
Model 1SAJ520000R0101 UMC100-FBP. 0 A4
Rated voltage 24-240 V AC/DC
Current range 0.24 A to 63 A
Working temperature -25 ° C to+70 ° C
FieldBusPlug (FBP) communication interface
Supports protocols such as Modbus, Profibus, Profinet, DeviceNet, etc
Installation method: DIN rail installation
Up to 6 digital inputs and 3 digital outputs for input and output
Protection functions include overload protection, short circuit protection, ground fault protection, and locked rotor protection
Display mode: Status LED or external HMI display
Protection level IP20
2.产 品 展 示
