Bently 3500/91 161204-01网关模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
Bently Nevada 3500/91 (161204-01) 网关模块 是一款用于连接和集成 Bently Nevada 3500 系列监测设备与外部系统的模块。它通过提供数据传输和通信功能，帮助用户将设备的实时数据和报警信息导入到中央监控系统，优化设备管理和故障响应。
产品概述
| 属性 | 详情 |
|---|---|
| 型号 | 3500/91 |
| 订货号 | 161204-01 |
| 设备类型 | 网关模块 |
| 系列 | Bently Nevada 3500 系列 |
| 主要功能 | 数据通信、远程监控、系统集成 |
| 安装位置 | 安装在 3500 框架中 |
关键特点
数据通信与集成：
- 提供与外部控制系统（如 DCS、PLC、SCADA 系统等）的通信能力。
- 支持多种通信协议，如 Modbus、Ethernet/IP、Profibus 等，确保与其他设备和系统的兼容性。
实时数据传输：
- 支持实时传输 3500 系列监测设备的数据，包括压力、温度、振动等参数。
- 可将设备的状态和报警信息发送到远程监控系统，帮助实现全天候设备健康监控。
报警与故障响应：
- 将设备的警报信息传递给上层系统，提供及时的报警通知。
- 支持多级报警输出（如告警、危险等），便于现场操作和控制。
多设备支持：
- 支持多个 3500 系列模块同时连接，简化系统部署。
- 可与多个 3500 监测模块集成，构建综合的设备监测和保护解决方案。
易于配置与维护：
- 支持灵活的配置和操作，通过简便的界面进行安装与设置。
- 具备诊断功能，可以帮助维护人员快速定位故障源。
英文资料：
The Bently Nevada 3500/91 (161204-01) Gateway Module is a module used to connect and integrate Bently Nevada 3500 series monitoring equipment with external systems. It helps users import real-time data and alarm information of devices into the central monitoring system by providing data transmission and communication functions, optimizing device management and fault response.
Product Overview
Attribute Details
Model 3500/91
Order number 161204-01
Device type gateway module
Bently Nevada 3500 Series
Main functions include data communication, remote monitoring, and system integration
Installation position: Installed in the 3500 frame
Key features
Data Communication and Integration:
Provide communication capabilities with external control systems such as DCS, PLC, SCADA systems, etc.
Supports multiple communication protocols such as Modbus, Ethernet/IP, Profibus, etc., ensuring compatibility with other devices and systems.
Real time data transmission:
Support real-time transmission of data from 3500 series monitoring devices, including parameters such as pressure, temperature, vibration, etc.
The status and alarm information of the device can be sent to the remote monitoring system to help achieve 24/7 device health monitoring.
Alarm and fault response:
Transmit the alarm information of the device to the upper level system and provide timely alarm notifications.
Support multi-level alarm output (such as alarm, danger, etc.) for easy on-site operation and control.
Multi device support:
Supports multiple 3500 series modules to be connected simultaneously, simplifying system deployment.
Can be integrated with multiple 3500 monitoring modules to build a comprehensive device monitoring and protection solution.
Easy to configure and maintain:
Support flexible configuration and operation, and install and set up through a simple interface.
Equipped with diagnostic functions, it can help maintenance personnel quickly locate the source of faults.
2.产 品 展 示
