Bently 3500/70M 140734-09动态压力监测器 PDF资料
1.产 品 资 料 介 绍：
中文资料：
Bently Nevada 3500/70M (140734-09) 动态压力监测器模块 是一款高度专业化的监测设备，专为实时监测工业设备的动态压力变化设计。该模块用于检测快速变化的压力信号，如燃气涡轮、压缩机或其他高动态压力设备的振动和冲击波，以保护设备并提高其运行效率。
产品概述
| 属性 | 详情 |
|---|---|
| 型号 | 3500/70M |
| 订货号 | 140734-09 |
| 设备类型 | 动态压力监测器模块 |
| 系列 | Bently Nevada 3500 系列 |
| 主要功能 | 实时动态压力监测、分析和报警 |
| 安装位置 | 安装在 3500 框架中 |
关键特点
动态压力监测：
- 专为检测快速变化的压力信号设计，适合高动态环境。
- 可捕捉与设备运行相关的压力脉冲、冲击波和振动信号。
高分辨率信号处理：
- 内置高性能数字信号处理（DSP）单元，可实时分析动态信号。
- 支持频率范围宽，适合捕捉高频压力变化。
报警和保护功能：
- 配备告警（Alert）和危险（Danger）级别的报警功能。
- 支持报警阈值的自定义设置，以适应不同设备和应用。
多通道输入：
- 提供多个压力传感器输入通道，每个通道可单独配置。
- 兼容多种动态压力传感器。
模块化设计：
- 支持热插拔，方便现场更换或升级，无需停机。
- 可与其他 3500 系列模块无缝集成，实现完整的设备监测和保护。
数据分析与通信：
- 可与系统控制中心连接，提供实时数据和历史趋势记录。
- 支持数据总线通信，与其他模块共享数据。
英文资料：
The Bently Nevada 3500/70M (140734-09) Dynamic Pressure Monitor Module is a highly specialized monitoring device designed for real-time monitoring of dynamic pressure changes in industrial equipment. This module is used to detect rapidly changing pressure signals, such as vibrations and shock waves from gas turbines, compressors, or other high dynamic pressure equipment, in order to protect the equipment and improve its operational efficiency.
Product Overview
Attribute Details
Model 3500/70M
Order number 140734-09
Equipment type: Dynamic pressure monitor module
Bently Nevada 3500 Series
Main functions: real-time dynamic pressure monitoring, analysis, and alarm
Installation position: Installed in the 3500 frame
Key features
Dynamic pressure monitoring:
Specially designed for detecting rapidly changing pressure signals, suitable for high dynamic environments.
Can capture pressure pulses, shock waves, and vibration signals related to device operation.
High resolution signal processing:
Built in high-performance digital signal processing (DSP) unit, capable of real-time analysis of dynamic signals.
Supports a wide frequency range, suitable for capturing high-frequency pressure changes.
Alarm and protection functions:
Equipped with Alert and Danger level alarm functions.
Support custom setting of alarm thresholds to adapt to different devices and applications.
Multi channel input:
Provide multiple pressure sensor input channels, each channel can be configured separately.
Compatible with multiple dynamic pressure sensors.
Modular design:
Support hot swapping, convenient for on-site replacement or upgrade, without the need for downtime.
It can seamlessly integrate with other 3500 series modules to achieve complete device monitoring and protection.
Data analysis and communication:
Can be connected to the system control center to provide real-time data and historical trend records.
Support data bus communication and share data with other modules.
2.产 品 展 示
