BENTLY 3500/40M 176449-01监视器 PDF资料
1.产 品 资 料 介 绍：
中文资料：
Bently Nevada 3500/40M 176449-01 监视器是3500系列机械保护和监测系统中的重要模块，专为监测关键设备的振动和轴位移而设计。它提供高精度的数据采集、处理和报警功能，帮助工业用户确保旋转机械的安全和可靠运行。
产品特点
多功能监测能力
- 专为关键旋转设备的振动、轴位置和运动参数监测设计。
- 支持多种输入信号源，包括涡流探头、加速度计和速度传感器。
模块化设计
- 可插入3500机架，方便与其他模块组合使用，满足复杂监测需求。
- 模块设计紧凑，便于安装、更换和系统扩展。
报警与关机保护
- 提供**警告（Alert）和危险（Danger）**双重报警级别。
- 支持逻辑配置，在设备异常时触发报警或关机信号。
先进的数据处理
- 内置滤波和数字信号处理（DSP）功能，确保监测数据的精准性。
- 支持多通道数据处理，每个通道均可独立配置。
诊断与状态指示
- 配备LED指示灯，显示模块状态和每个通道的运行情况，便于快速诊断。
英文资料：
The Bently Nevada 3500/40M 176449-01 monitor is an important module in the 3500 series mechanical protection and monitoring system, designed specifically for monitoring vibration and shaft displacement of critical equipment. It provides high-precision data acquisition, processing, and alarm functions to help industrial users ensure the safe and reliable operation of rotating machinery.
Product Features
Multi functional monitoring capability
Specially designed for monitoring vibration, shaft position, and motion parameters of critical rotating equipment.
Supports multiple input signal sources, including eddy current probes, accelerometers, and velocity sensors.
Modular design
Can be inserted into 3500 racks for easy combination with other modules to meet complex monitoring needs.
The module design is compact, making it easy to install, replace, and expand the system.
Alarm and shutdown protection
Provide dual alarm levels of * * Alert and Danger * *.
Support logical configuration, triggering alarms or shutdown signals when the device is abnormal.
Advanced data processing
Built in filtering and digital signal processing (DSP) functions ensure the accuracy of monitoring data.
Support multi-channel data processing, each channel can be independently configured.
Diagnosis and status indication
Equipped with LED indicator lights to display module status and the operation status of each channel for quick diagnosis.
2.产 品 展 示
