GE IC3600SVSAIE直流电源供应板 PDF资料
1.产 品 资 料 介 绍：
中文资料：
IC3600SVSAIE直流电源供应板 是通用电气（GE）Mark系列控制系统中的一个关键组件，主要用于为系统提供稳定的直流电源。此类电源板通常用于支持工业自动化、涡轮控制及其他高要求的电子系统，确保这些系统能够稳定工作并提供精确的控制和保护功能。
功能与特点
提供直流电源：
- 为系统中的各个模块提供必要的直流电压（如5V、12V、24V DC等），保证电路的正常运行。
电压稳压与滤波：
- 电源板通常内置稳压电路，确保输出电压稳定，同时减少电源噪声对系统的影响。
多通道输出：
- 可能支持多个电压输出通道，以满足不同组件的电源需求。
过载保护：
- 内置过载保护机制，防止电源过载或短路导致的设备损坏。
热管理：
- 高效的热散管理设计，防止过热，保证设备的长时间稳定运行。
高可靠性：
- 适用于苛刻的工业环境，具备耐高温、抗振动、抗电磁干扰等特性。
技术规格
输入/输出电压：
- 输入电压范围：通常为 24V 或 110V AC，根据型号有所不同。
- 输出电压：常见为 5V、12V、24V DC，适用于不同设备。
功率容量：
- 输出功率一般会根据系统需求不同而有所变化，通常为几百瓦到上千瓦不等。
保护功能：
- 过载、短路保护：确保电源板及整个系统在异常情况下不会损坏。
- 温度保护：内置温度传感器，防止过热。
接口类型：
- 通常通过标准化接口与系统主控制单元连接。
工作环境：
- 工作温度：-40°C 至 +70°C（视型号而定）。
- 湿度范围：5%-95%（无冷凝）。
物理尺寸：
- 根据系统要求，设计适配于GE Mark系列机架或其他控制柜中。
英文资料：
The IC3600SVSAIE DC power supply board is a key component in the General Electric (GE) Mark series control system, primarily used to provide stable DC power to the system. This type of power board is typically used to support industrial automation, turbine control, and other high demand electronic systems, ensuring that these systems can operate stably and provide precise control and protection functions.
Function and Features
Provide DC power supply:
Provide necessary DC voltages (such as 5V, 12V, 24V DC, etc.) for each module in the system to ensure the normal operation of the circuit.
Voltage stabilization and filtering:
Power boards usually have built-in voltage stabilization circuits to ensure stable output voltage and reduce the impact of power supply noise on the system.
Multi channel output:
It may support multiple voltage output channels to meet the power requirements of different components.
Overload protection:
Built in overload protection mechanism to prevent equipment damage caused by power overload or short circuit.
Thermal management:
Efficient heat dissipation management design to prevent overheating and ensure long-term stable operation of equipment.
High reliability:
Suitable for harsh industrial environments, it has characteristics such as high temperature resistance, vibration resistance, and electromagnetic interference resistance.
technical specifications
Input/output voltage:
Input voltage range: usually 24V or 110V AC, depending on the model.
Output voltage: commonly 5V, 12V, 24V DC, suitable for different devices.
Power capacity:
The output power generally varies depending on the system requirements, typically ranging from a few hundred watts to several kilowatts.
Protection function:
Overload and short circuit protection: Ensure that the power board and the entire system are not damaged in case of abnormal conditions.
Temperature protection: Built in temperature sensor to prevent overheating.
Interface type:
Usually connected to the system main control unit through standardized interfaces.
Work environment:
Working temperature:- 40 ° C to+70 ° C (depending on the model).
Humidity range: 5% -95% (without condensation).
Physical dimensions:
Design and adapt to GE Mark series racks or other control cabinets according to system requirements.
