GE IC3600SOTE温度控制器模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
GE IC3600SOTE 是一款温度控制器模块，设计用于 GE 的 Speedtronic 系列控制系统，特别是在燃气和蒸汽涡轮机控制领域中，执行温度监测和管理任务。以下是该模块的详细信息：
产品特点
核心功能：
- 实时监测系统温度并提供精准的温度控制。
- 将温度信号转换为控制系统可用的逻辑信号，以调整涡轮机或其他工业设备的运行参数。
设计特点：
- 板载多种组件，包括热敏电阻、电阻器、电容器和运算放大器，确保信号的准确性和稳定性。
- 集成化设计，适合 GE 控制系统的模块化插槽。
接口与连接：
- 标准化的插针和连接器设计，与 Speedtronic 系统无缝兼容。
- 提供输入端口用于接收温度传感器信号，输出端口用于传递控制信号。
可靠性：
- 工业级组件，适合严苛的运行环境。
- 具备抗电磁干扰（EMI）和环境噪声的特性。
技术规格
温度测量范围：
- 通常可测量 -40°C 至 +120°C，具体范围依赖于连接的温度传感器类型。
工作电压：
- 通常为 24V 或 48V DC（与控制系统匹配）。
信号类型：
- 输入：模拟信号（来自热电偶或热敏电阻）。
- 输出：数字或模拟信号，传递至控制单元。
工作环境：
- 温度：-20°C 至 +70°C。
- 湿度：0%-95%（无冷凝）。
尺寸与兼容性：
- 符合 Speedtronic 系统标准化设计，便于快速安装和更换。
英文资料：
GE IC3600SOTE is a temperature controller module designed for use in GE's Speedtronic series control systems, particularly in the field of gas and steam turbine control, to perform temperature monitoring and management tasks. The following is the detailed information of the module:
Product Features
Core functions:
Real time monitoring of system temperature and providing precise temperature control.
Convert temperature signals into logic signals that can be used by the control system to adjust the operating parameters of turbines or other industrial equipment.
Design features:
On board multiple components, including thermistors, resistors, capacitors, and operational amplifiers, ensure signal accuracy and stability.
Integrated design, suitable for modular slots in GE control systems.
Interface and Connection:
Standardized pin and connector design, seamlessly compatible with the Speedtronic system.
Provide input ports for receiving temperature sensor signals and output ports for transmitting control signals.
Reliability:
Industrial grade components suitable for harsh operating environments.
Capable of resisting electromagnetic interference (EMI) and environmental noise.
technical specifications
Temperature measurement range:
Usually, it can measure from -40 ° C to+120 ° C, depending on the type of temperature sensor connected.
Working voltage:
Usually 24V or 48V DC (matched with the control system).
Signal type:
Input: Analog signal (from thermocouple or thermistor).
Output: Digital or analog signal, transmitted to the control unit.
Work environment:
Temperature:- 20 ° C to+70 ° C.
Humidity: 0% -95% (no condensation).
Size and compatibility:
Compliant with Speedtronic system standardization design, easy to install and replace quickly.
