GE IC3600LIVD1A逻辑逆变器 PDF资料
1.产 品 资 料 介 绍：
中文资料：
GE IC3600LIVD1A 是一款逻辑逆变器模块，属于 GE 的 Speedtronic 系列工业控制系统的一部分，广泛应用于工业自动化和涡轮机控制系统中。以下是关于 IC3600LIVD1A 的详细信息：
产品特点
核心功能：
- 用于信号逻辑逆变操作，将输入信号的逻辑状态反转（例如，高电平变为低电平，或低电平变为高电平）。
- 支持数字信号的可靠处理，确保逻辑电路的准确性。
设计特点：
- 板载多个电子元件，包括晶体管、电阻器、电容器和集成电路，优化了逻辑处理性能。
- 紧凑型设计，适用于 GE 控制系统中的标准插槽。
接口与连接：
- 标准化的金属插脚设计，确保与 Speedtronic 系统的兼容性。
- 多针连接器，便于快速集成到现有系统中。
可靠性：
- 工业级组件设计，确保在恶劣环境下的稳定运行。
- 具有抗电磁干扰（EMI）的特性，适合复杂的工业环境。
技术规格
- 逻辑操作：反转输入信号逻辑状态。
- 工作电压：与 Speedtronic 系统一致，通常为 5V 或 24V 直流（根据具体应用）。
- 工作环境：
- 温度范围：-20°C 至 +70°C。
- 湿度范围：0%-95%（无冷凝）。
- 尺寸与兼容性：符合 GE Mark 系列控制系统标准。
应用领域
工业自动化：
- 用于逻辑电路中的信号逆变，作为其他控制模块的辅助部分。
涡轮机控制：
- 作为 GE Mark I 和 Mark II 系统的组成部分，确保燃气或蒸汽涡轮机的高效运行。
能源管理：
- 在复杂逻辑控制过程中，用于优化信号处理与系统响应。
英文资料：
GE IC3600LIVD1A is a logic inverter module that is part of GE's Speedtronic series of industrial control systems, widely used in industrial automation and turbine control systems. The following is detailed information about IC3600LIVD1A:
Product Features
Core functions:
Used for signal logic inversion operation, to invert the logic state of the input signal (e.g., high level to low level, or low level to high level).
Support reliable processing of digital signals to ensure the accuracy of logic circuits.
Design features:
On board multiple electronic components, including transistors, resistors, capacitors, and integrated circuits, optimize logic processing performance.
Compact design, suitable for standard slots in GE control systems.
Interface and Connection:
Standardized metal pin design ensures compatibility with the Speedtronic system.
Multi pin connectors facilitate quick integration into existing systems.
Reliability:
Industrial grade component design ensures stable operation in harsh environments.
It has the characteristic of resisting electromagnetic interference (EMI) and is suitable for complex industrial environments.
technical specifications
Logical operation: Invert the logical state of the input signal.
Working voltage: Consistent with the Speedtronic system, typically 5V or 24V DC (depending on the specific application).
Work environment:
Temperature range:- 20 ° C to+70 ° C.
Humidity range: 0% -95% (without condensation).
Size and compatibility: Complies with GE Mark series control system standards.
application area
Industrial automation:
Used for signal inversion in logic circuits, as an auxiliary part of other control modules.
Turbine control:
As a component of the GE Mark I and Mark II systems, ensure efficient operation of gas or steam turbines.
Energy Management:
Used to optimize signal processing and system response in complex logic control processes.
