Vanguard CPCI-10-D2机箱 PDF资料
1.产 品 资 料 介 绍：
中文资料：
Vanguard CPCI-10-D2 机箱 是一款用于工业级应用的 紧凑型 PCI (CPCI) 系统机箱，专为高性能计算和控制系统设计。该机箱具有出色的散热能力、模块化设计和强大的扩展性，广泛应用于通信、自动化、国防、交通和工业控制领域。
核心特点：
紧凑型设计
- 采用 3U 或 6U CPCI 标准，确保高性能与小巧尺寸相结合，便于在受限空间中安装。
模块化架构
- 提供多个 CPCI 插槽，便于扩展 CPU、I/O 模块、电源等多种功能。
- 支持系统管理模块（如风扇控制、电源监控）与应用模块。
高可靠性与稳定性
- 工业级设计，适应严苛的工作环境，包括高温、振动、湿度等条件。
- 支持长时间稳定运行，适用于 7x24 小时连续工作场景。
高效散热设计
- 内置高性能冷却风扇，优化风道设计，确保模块在高负载下维持低温运行。
- 支持可更换式风扇，便于维护与升级。
高电源冗余与灵活性
- 支持冗余电源系统，确保供电稳定，避免因电源故障导致系统停机。
- 提供多种电源配置（如 250W、500W 等），满足不同系统功耗需求。
易维护性
- 提供模块化设计，便于插拔板卡与更换故障模块，减少系统停机时间。
技术规格：
- 机箱类型：CPCI 标准机箱
- 插槽数量：
- 10 个 CompactPCI (CPCI) 插槽
- 支持系统插槽 + 扩展 I/O 插槽
- 外形尺寸：
- 3U/6U 尺寸，适应标准机架安装
- 材质：高强度铝合金外壳，具备抗振与耐腐蚀特性
- 电源系统：
- 冗余电源，支持 250W 至 500W 功率
- 输入电压：AC 100-240V，50/60Hz
- 散热系统：
- 高效冷却风扇（前后或侧面风道设计）
- 风扇转速自动调节，降低噪音
- 环境参数：
- 工作温度：0°C 至 +55°C
- 存储温度：-40°C 至 +85°C
- 湿度范围：5%-95%（非冷凝）
- 抗振动：符合 IEC 60068 标准
- 安装方式：
- 19 英寸标准机架安装
- 台式或壁挂安装选项
- 支持设备：
- CPCI 单板计算机 (SBC)
- I/O 模块
- 电源模块
- 扩展模块
英文资料：
The Vanguard CPCI-10-D2 chassis is a compact PCI (CPCI) system chassis designed for industrial applications, specifically for high-performance computing and control systems. This chassis has excellent heat dissipation capability, modular design, and strong scalability, and is widely used in the fields of communication, automation, defense, transportation, and industrial control.
Core features:
Compact design
Adopting 3U or 6U CPCI standards ensures a combination of high performance and compact size, making it easy to install in confined spaces.
Modular architecture
Provide multiple CPCI slots for easy expansion of CPU, I/O modules, power supply, and other functions.
Support system management modules (such as fan control, power monitoring) and application modules.
High reliability and stability
Industrial grade design, suitable for harsh working environments, including high temperatures, vibrations, humidity, and other conditions.
Supports long-term stable operation and is suitable for 7x24 hour continuous work scenarios.
Efficient heat dissipation design
Built in high-performance cooling fan, optimized air duct design to ensure module maintains low-temperature operation under high loads.
Support replaceable fans for easy maintenance and upgrades.
High power redundancy and flexibility
Support redundant power supply system to ensure stable power supply and avoid system shutdown caused by power failure.
Provide multiple power configurations (such as 250W, 500W, etc.) to meet the power consumption requirements of different systems.
Maintainability
Provide modular design for easy insertion and removal of boards and replacement of faulty modules, reducing system downtime.
Technical specifications:
Chassis type: CPCI standard chassis
Number of slots:
10 CompactPCI (CPCI) slots
Support system slots+expansion I/O slots
External dimensions:
3U/6U size, suitable for standard rack installation
Material: High strength aluminum alloy shell, with anti vibration and anti-corrosion properties
Power system:
Redundant power supply, supporting 250W to 500W power
Input voltage: AC 100-240V，50/60Hz
Cooling system:
Efficient cooling fan (front, rear or side air duct design)
Automatic adjustment of fan speed to reduce noise
Environmental parameters:
Working temperature: 0 ° C to+55 ° C
Storage temperature:- 40 ° C to+85 ° C
Humidity range: 5% -95% (non condensing)
Anti vibration: Complies with IEC 60068 standard
Installation method:
19 inch standard rack installation
Desktop or wall mounted installation options
Supporting devices:
CPCI Single Board Computer (SBC)
I/O module
Power module
Expansion module
