CLIPPARD R311气动阀 PDF资料
1.产 品 资 料 介 绍：
中文资料：
Clippard R311 气动阀 是由 Clippard Instrument Laboratory, Inc. 设计和制造的高性能 3/2 通气动阀，广泛应用于自动化控制系统、气动设备和流体控制应用中。它以高可靠性、紧凑设计和精确控制著称，适用于多种工业和实验室环境。
核心功能：
3/2 通功能
- 具备三个端口和两种切换状态，提供开/关控制或通断功能。
- 支持进气、排气和输出的流体路径切换。
精确控制与响应速度快
- 提供快速响应，适用于需要精确时间控制的应用。
- 控制稳定，保证流体或气体的顺畅流通。
手动与自动切换操作
- 支持气动控制或手动操作，适应不同的应用场景。
紧凑设计
- 小巧的外形尺寸便于集成到有限空间的系统中。
高耐用性与低维护
- 采用高质量材料，确保长寿命和高可靠性。
- 设计简单，易于维护与更换。
技术规格：
- 型号：R311
- 阀类型：3/2 通气动阀
- 功能：单动常闭（Normally Closed）或常开（Normally Open）
- 操作方式：手动/气动切换
- 工作压力范围：0 至 300 PSI（0-20.7 bar）
- 流量系数 (Cv)：0.05
- 工作介质：
- 气体（经过过滤和干燥的压缩空气）
- 非腐蚀性气体
- 响应时间：快速切换（具体时间取决于压力和系统要求）
- 温度范围：-18°C 至 +70°C（0°F 至 160°F）
- 材质：
- 阀体：黄铜或不锈钢
- 密封件：高性能弹性材料（如 Nitrile 或 Viton）
- 接口尺寸：1/8” NPT 螺纹连接
- 重量：轻巧，约 0.2 磅（90 克）
英文资料：
The Clippard R311 pneumatic valve is a high-performance 3/2 pneumatic valve designed and manufactured by Clippard Instrument Laboratory, Inc. It is widely used in automation control systems, pneumatic equipment, and fluid control applications. It is known for its high reliability, compact design, and precise control, and is suitable for a variety of industrial and laboratory environments.
Core functions:
3/2-way function
It has three ports and two switching states, providing on/off control or on-off function.
Support fluid path switching for intake, exhaust, and output.
Accurate control and fast response speed
Provide fast response, suitable for applications that require precise time control.
Control stability to ensure smooth flow of fluids or gases.
Manual and automatic switching operation
Support pneumatic control or manual operation, suitable for different application scenarios.
Compact design
The compact size makes it easy to integrate into systems with limited space.
High durability and low maintenance
Using high-quality materials to ensure long lifespan and high reliability.
Simple design, easy to maintain and replace.
Technical specifications:
Model: R311
Valve type: 3/2 vent valve
Function: Single action normally closed or normally open
Operation mode: manual/pneumatic switching
Working pressure range: 0 to 300 PSI (0-20.7 bar)
Flow coefficient (Cv): 0.05
Working medium:
Gas (filtered and dried compressed air)
Non corrosive gas
Response time: Fast switching (specific time depends on pressure and system requirements)
Temperature range: -18 ° C to+70 ° C (0 ° F to 160 ° F)
texture of material:
Valve body: brass or stainless steel
Sealing element: High performance elastic material (such as Nitrile or Viton)
Interface size: 1/8 "NPT threaded connection
Weight: Lightweight, approximately 0.2 pounds (90 grams)
2.产 品 展 示
