CCC TMPU-1002转换模块 PDF资料
1.产 品 资 料 介 绍：
中文资料：
CCC TMPU-1002 转换模块 是由 Compressor Controls Corporation (CCC) 设计的工业级信号转换模块，专用于工业控制系统中信号处理和转换，确保数据在不同设备和系统之间高效、精准传输。它在压缩机和涡轮机控制应用中表现突出，广泛用于石油天然气、电力、化工等领域。
核心功能：
信号转换与处理
- 将输入信号（如模拟信号、数字信号）转换为系统所需的标准信号格式。
- 确保信号在控制系统中的兼容性与稳定传输。
数据传输与通信
- 支持多种工业标准通信协议（如 Modbus、Profibus 等），实现与上位机或其他模块之间的数据交换。
- 提供高效、低延迟的数据传输，保障实时控制需求。
信号隔离与保护
- 提供电气隔离，防止信号干扰，提升系统的抗噪性与可靠性。
- 保护设备免受过电压和浪涌影响。
模块化设计
- 紧凑的模块化设计便于安装、集成和维护。
- 支持与其他 CCC 控制模块无缝集成，扩展系统功能。
高可靠性与稳定性
- 工业级设计，适应恶劣环境（高温、湿度、振动等）。
- 具备长时间稳定运行的能力，减少系统故障风险。
技术规格：
- 型号：TMPU-1002
- 功能：信号转换与隔离
- 输入信号：支持多种模拟和数字输入格式
- 输出信号：标准工业控制信号（如 4-20mA、0-10V）
- 通信接口：
- Modbus
- Profibus
- 其他工业通信协议
- 电气隔离：输入/输出通道之间提供高效电气隔离
- 供电电压：24V DC
- 工作温度：-40°C 至 +70°C
- 湿度范围：5% 至 95%（非冷凝）
- 安装方式：DIN 导轨或机架安装
- 模块化设计：支持快速更换与维护
应用领域：
- 压缩机与涡轮机控制系统
- 提供高精度信号转换，确保控制系统与传感器、执行器的兼容性。
- 石油与天然气行业
- 适用于复杂工艺流程中的数据转换与传输，确保系统稳定运行。
- 化工与电力行业
- 在关键工艺控制环节中提供高可靠性的数据传输与隔离保护。
- 工业自动化与过程控制
- 实现多设备间的信号转换与集成，优化自动化控制流程。
英文资料：
The CCC TMPU-1002 conversion module is an industrial grade signal conversion module designed by Compressor Controls Corporation (CCC), dedicated to signal processing and conversion in industrial control systems, ensuring efficient and accurate transmission of data between different devices and systems. It performs outstandingly in compressor and turbine control applications and is widely used in fields such as oil and gas, electricity, and chemical engineering.
Core functions:
Signal Conversion and Processing
Convert input signals (such as analog and digital signals) into the standard signal format required by the system.
Ensure compatibility and stable transmission of signals in the control system.
Data transmission and communication
Support multiple industrial standard communication protocols (such as Modbus, Profibus, etc.) to achieve data exchange with the upper computer or other modules.
Provide efficient and low latency data transmission to ensure real-time control requirements.
Signal isolation and protection
Provide electrical isolation to prevent signal interference and enhance the system's noise resistance and reliability.
Protect equipment from overvoltage and surge effects.
Modular design
The compact modular design facilitates installation, integration, and maintenance.
Support seamless integration with other CCC control modules to expand system functionality.
High reliability and stability
Industrial grade design, suitable for harsh environments such as high temperature, humidity, vibration, etc.
Capable of long-term stable operation, reducing the risk of system failure.
Technical specifications:
model: TMPU-1002
Function: Signal conversion and isolation
Input signal: Supports multiple analog and digital input formats
Output signal: Standard industrial control signal (such as 4-20mA, 0-10V)
Communication interface:
Modbus
Profibus
Other industrial communication protocols
Electrical isolation: Provide efficient electrical isolation between input/output channels
Power supply voltage: 24V DC
Working temperature:- 40 ° C to+70 ° C
Humidity range: 5% to 95% (non condensing)
Installation method: DIN rail or rack installation
Modular design: supports quick replacement and maintenance
Application areas:
Compressor and turbine control system
Provide high-precision signal conversion to ensure compatibility between control systems, sensors, and actuators.
Oil and gas industry
Suitable for data conversion and transmission in complex process flows, ensuring stable system operation.
Chemical and power industries
Provide high reliability data transmission and isolation protection in critical process control links.
Industrial Automation and Process Control
Realize signal conversion and integration between multiple devices, optimize automation control processes.
