Motorola MVME2400-0361 单板计算机 PDF资料

1.产 品 资 料 介 绍：

中文资料：

Motorola MVME2400-0361 单板计算机 是 Motorola（现为 NXP Semiconductors）生产的一款高性能 VME（Versa Modular Europe）总线 兼容的单板计算机。它通常应用于工业自动化、嵌入式计算、军事和航天等领域，提供可靠的计算和控制能力，适用于需要高性能和长期稳定性的环境。

主要特点：

1. 高性能处理器：

• MVME2400-0361 配备了一款 PowerPC 603e 处理器，主频高达 180 MHz。
• PowerPC 架构广泛应用于嵌入式系统，具有出色的计算能力和高效能。

2. VME 总线兼容：

• 支持 VME 64 总线（版本 3.x），提供 高带宽 和 高速数据传输，适合需要大数据量处理的系统。
• 可作为 主控制单元 或 从设备 使用，支持多个并行工作模块。

3. 内存与扩展性：

• 提供高达 128 MB 的 SDRAM（可以根据具体配置有所不同），满足大多数嵌入式计算需求。
• 具有 2 MB 的 Flash 存储，可用于存储系统固件和应用程序。
• 支持扩展内存，并通过 PCMCIA 插槽 支持其他存储设备（如 CF 卡等）。

4. 多种 I/O 接口：

• 配备 串口、并口、网络接口（如 10/100 Ethernet），支持 USB 接口等，能够与各种外部设备和控制系统连接。
• 提供 数字 I/O 和 模拟 I/O 接口，可以用于传感器采集、执行器控制等任务。

5. 操作系统支持：

• 支持多种操作系统，包括 VxWorks、Linux 和 RTOS（实时操作系统），使得它能够适应各种实时性和稳定性要求的应用。

6. 冗余和可靠性：

• 该单板计算机设计具有 高可靠性，可以长期稳定运行，适应 恶劣环境（如高温、低温和振动等）下的应用。
• 配备了 看门狗定时器、硬件故障检测等功能，确保系统在出现故障时能及时恢复或报警。

7. 图形与显示功能：

• 提供 图形加速器，适用于需要图形用户界面的应用（如 HMI 监控、工业控制显示等）。

应用领域：

1. 工业自动化：

• 用于控制系统、数据采集、监测和分析等工业应用。MVME2400 常见于 PLC 控制系统、机器人控制等场合。

2. 嵌入式系统：

• 在 医疗设备、通信设备、航天系统等嵌入式系统中得到广泛应用，支持实时数据处理和控制。

3. 军事和航天：

• 因其高可靠性和稳定性，MVME2400 系列广泛用于 军事 和 航天 应用，尤其是在需要高耐久性的控制系统中。

4. 交通与物流：

• 用于 智能交通系统、运输监控系统，以及 高速铁路、航空航天等系统中，进行实时数据处理和监控。

技术规格：

英文资料：

The Motorola MVME2400-0361 single board computer is a high-performance VME (Versa Modular Europe) bus compatible single board computer produced by Motorola (now NXP Semiconductors). It is commonly used in fields such as industrial automation, embedded computing, military, and aerospace, providing reliable computing and control capabilities, suitable for environments that require high performance and long-term stability.

Main features:

High performance processor:

MVME2400-0361 is equipped with a PowerPC 603e processor with a clock speed of up to 180 MHz.

The PowerPC architecture is widely used in embedded systems and has excellent computing power and high efficiency.

VME bus compatibility:

Supports VME 64 bus (version 3. x), providing high bandwidth and high-speed data transmission, suitable for systems that require large amounts of data processing.

Can be used as a master control unit or slave device, supporting multiple parallel working modules.

Memory and Scalability:

Provide up to 128 MB of SDRAM (which may vary depending on specific configurations) to meet most embedded computing needs.

Featuring 2 MB of Flash storage, it can be used to store system firmware and applications.

Support for expanding memory and supporting other storage devices (such as CF cards) through PCMCIA slots.

Multiple I/O interfaces:

Equipped with serial port, parallel port, network interface (such as 10/100 Ethernet), supporting USB interface, etc., it can connect with various external devices and control systems.

Provide digital I/O and analog I/O interfaces, which can be used for tasks such as sensor acquisition and actuator control.

Operating system support:

Supports multiple operating systems, including VxWorks, Linux, and RTOS (real-time operating system), enabling it to adapt to applications with various real-time and stability requirements.

Redundancy and reliability:

This single board computer design has high reliability, can operate stably for a long time, and is suitable for applications in harsh environments such as high temperature, low temperature, and vibration.

Equipped with watchdog timer, hardware fault detection and other functions to ensure timely recovery or alarm in case of system failure.

Graphics and display functions:

Provide a graphics accelerator suitable for applications that require a graphical user interface, such as HMI monitoring, industrial control displays, etc.

Application areas:

Industrial automation:

Used for industrial applications such as control systems, data acquisition, monitoring, and analysis. MVME2400 is commonly used in PLC control systems, robot control, and other applications.

Embedded system:

Widely used in embedded systems such as medical equipment, communication equipment, and aerospace systems, it supports real-time data processing and control.

Military and Aerospace:

Due to its high reliability and stability, the MVME2400 series is widely used in military and aerospace applications, especially in control systems that require high durability.

Transportation and Logistics:

Used for real-time data processing and monitoring in intelligent transportation systems, transportation monitoring systems, as well as high-speed railway, aerospace and other systems.

Technical specifications:

Parameter Description

Processor PowerPC 603e, 180 MHz

Memory 128 MB SDRAM

Store 2 MB of Flash

VME Bus VME 64 (Version 3. x)

Network interface 10/100 Ethernet (optional high-speed Ethernet interface)

Serial ports 4 x RS-232 or 2 x RS-232 and 1 x RS-422/485

I/O interfaces include digital I/O, analog I/O, serial port, USB, parallel port, etc

Expansion slot 1 x PMC slot, 1 x PCMCIA slot

Power requirement+5V DC (standard power input)

Size 6U (233 x 160 x 40 mm)

The operating system supports VxWorks, Linux, RTOS (real-time operating system)

The protection level meets the requirements of industrial environment, with anti vibration, dust-proof, and waterproof properties

2.产      品      展      示
