EATON-MOELLER XV-363-10-C02-A00-1B 触摸屏 PDF资料
1.产 品 资 料 介 绍：
中文资料：
EATON-MOELLER XV-363-10-C02-A00-1B 触摸屏 是由 Eaton（伊顿）和 Moeller（莫勒）联合生产的一款工业控制面板触摸屏。它被广泛应用于自动化控制、过程监控和数据可视化系统中，为操作人员提供直观、易于操作的界面。
主要特点：
高分辨率触摸屏：
- XV-363-10-C02-A00-1B 配备了高分辨率的触摸显示屏，能够清晰显示各种数据和图形界面，提升用户体验。
- 支持 TFT LCD 屏幕，显示效果细腻，适合长时间显示监控数据。
多功能显示与控制：
- 可以显示实时过程数据、系统状态和报警信息。
- 支持 触摸操作，用户可以直接通过触摸屏进行操作、参数调整和系统控制，简化了用户交互方式。
强大的通信接口：
- 支持多种工业通信协议，如 Modbus RTU/TCP、CANopen、Profibus 等，能够与各种控制设备和自动化系统（如 PLC、DCS 等）无缝连接，确保数据传输的稳定性和实时性。
灵活的界面定制：
- 用户可以根据需求进行界面设计和定制，支持图标、按钮、曲线图等多种元素的自定义，适应不同的应用场景。
- 配合Eaton的 Xsoft-CoDeSys 或其他编程工具进行图形界面开发，满足复杂的监控需求。
高可靠性和耐用性：
- 该触摸屏具有 工业级耐用性，可以在恶劣环境下稳定工作，包括较高的温度、湿度和电磁干扰。
- 采用 坚固的外壳，防尘、防水、抗振动，适合工厂车间等工业环境。
操作简便：
- 触摸屏操作直观简便，配合定制的图形用户界面（GUI），使得操作员可以快速了解系统状态，进行必要的控制和调整。
- 触摸响应灵敏，减少了传统按钮操作的复杂性。
应用领域：
- 工业自动化控制： 用于监控和控制生产线、机械设备、自动化装置等。
- 过程监控： 在化工、食品饮料、电力等领域的生产过程监控中，提供实时数据展示和报警控制。
- 楼宇自动化： 用于建筑管理系统（BMS），包括空调、照明、安全监控等系统的控制。
- 机械设备控制： 可用于各种机械设备的操作面板，提供实时的状态信息和控制接口。
技术规格：
| 参数 | 说明 |
|---|---|
| 显示类型 | 触摸式TFT LCD显示屏 |
| 分辨率 | 320 x 240（可能视具体型号而定） |
| 触摸方式 | 电阻式触摸或电容式触摸（具体依型号而定） |
| 通信接口 | Modbus RTU/TCP, CANopen, Profibus 等 |
| 输入电压 | 24V DC（典型） |
| 操作温度范围 | -10°C 至 +60°C |
| 安装方式 | 面板安装或嵌入式安装 |
| 尺寸 | 根据具体型号尺寸而定（通常为 3.5 英寸到 12 英寸） |
| 防护等级 | IP65（前面板防水防尘） |
| 外壳材料 | 耐用塑料或金属外壳，具备抗电磁干扰能力 |
英文资料：
The EATON-MOELLER XV-363-10-C02-A00-1B touch screen is an industrial control panel touch screen jointly produced by Eaton and Moeller. It is widely used in automation control, process monitoring, and data visualization systems, providing operators with an intuitive and easy-to-use interface.
Main features:
High resolution touch screen:
XV-363-10-C02-A00-1B is equipped with a high-resolution touch screen display, which can clearly display various data and graphical interfaces, enhancing the user experience.
Supports TFT LCD screen with delicate display effect, suitable for long-term display of monitoring data.
Multi functional display and control:
It can display real-time process data, system status, and alarm information.
Support touch operation, users can directly operate, adjust parameters, and control the system through the touch screen, simplifying user interaction.
Powerful communication interface:
Supporting multiple industrial communication protocols such as Modbus RTU/TCP, CANopen, Profibus, etc., it can seamlessly connect with various control devices and automation systems (such as PLC, DCS, etc.), ensuring the stability and real-time performance of data transmission.
Flexible interface customization:
Users can design and customize the interface according to their needs, supporting customization of various elements such as icons, buttons, and curve graphs to adapt to different application scenarios.
Collaborate with Eaton's Xsoft CodeSys or other programming tools for graphical interface development to meet complex monitoring requirements.
High reliability and durability:
This touch screen has industrial grade durability and can work stably in harsh environments, including high temperatures, humidity, and electromagnetic interference.
Adopting a sturdy shell, dustproof, waterproof, and vibration resistant, suitable for industrial environments such as factory workshops.
Easy to operate:
The touch screen operation is intuitive and simple, coupled with a customized graphical user interface (GUI), allowing operators to quickly understand the system status and make necessary controls and adjustments.
The touch response is sensitive, reducing the complexity of traditional button operations.
Application areas:
Industrial automation control: used for monitoring and controlling production lines, mechanical equipment, automation devices, etc.
Process monitoring: Provide real-time data display and alarm control in the production process monitoring of chemical, food and beverage, power and other fields.
Building automation: used for controlling building management systems (BMS), including air conditioning, lighting, safety monitoring, and other systems.
Mechanical equipment control: It can be used as an operation panel for various mechanical equipment, providing real-time status information and control interfaces.
Technical specifications:
Parameter Description
Display type: Touch sensitive TFT LCD display screen
Resolution 320 x 240 (may vary depending on specific model)
Touch method: resistive touch or capacitive touch (depending on the model)
Communication interfaces such as Modbus RTU/TCP, CANopen, Profibus, etc
Input voltage 24V DC (typical)
Operating temperature range -10 ° C to+60 ° C
Installation method: panel installation or embedded installation
The size depends on the specific model size (usually 3.5 inches to 12 inches)
Protection level IP65 (front panel waterproof and dustproof)
Durable plastic or metal shell material with anti electromagnetic interference capability
