Motorola MVME167-33B工业控制系统 PDF资料

1.产 品 资 料 介 绍：

中文资料：

Motorola MVME167-33B 是一款基于 VMEbus 架构的高性能工业控制系统，广泛用于嵌入式计算、工业自动化、数据采集、通信控制等领域。该系统由 Motorola（现为 NXP 半导体）设计和制造，能够在严苛的工业环境中提供可靠的性能。

MVME167-33B 主要特点：

1. 处理器和性能：

• 配备 33 MHz 的 Motorola 68040 RISC 处理器，具有较高的处理能力，适合需要较强计算和实时控制的应用。
• 支持多任务操作系统，如 VxWorks、RTEMS 等实时操作系统（RTOS），实现实时控制功能。

2. 内存配置：

• 提供最大 128 MB DRAM（动态随机存取内存），以满足高带宽数据处理和存储需求。
• 支持 Flash 存储（通常为 4 MB 或更大），用于存储固件、应用程序和操作系统。

3. VMEbus 架构：

• 采用 VMEbus 标准，可提供高效的数据传输速度和扩展性，支持多种 VMEbus 模块和外设。
• 支持 VME 64-bit 扩展，带宽更高，适合数据密集型应用。

4. I/O 接口：

• 提供多个 串口接口（如 RS-232 和 RS-422），用于通信和数据交换。
• 具有 Ethernet 网络接口，支持工业以太网通信和远程数据传输。
• 多个 GPIO（通用输入/输出） 接口，可连接传感器、执行器等外部设备。

5. 操作系统支持：

• 兼容多种实时操作系统（RTOS），包括 VxWorks、Linux、RTEMS 等，灵活支持各种工业应用需求。
• 支持 DOS 和 Windows 操作系统的基本应用。

6. 扩展性：

• 提供多个 扩展插槽，支持额外的 I/O 模块和专用卡片，可以根据具体需求扩展功能。
• 具有 PMC（PCI Mezzanine Card）插槽，可添加其他硬件模块。

7. 可靠性与耐用性：

• 设计用于工业级环境，具有较高的抗干扰能力和热稳定性。
• 具备强大的错误检测和容错能力，以保证系统稳定运行。
• 支持 温度范围：-40°C 至 +85°C，适合极端环境条件。

8. 通信和网络能力：

• 支持 Ethernet 网络接口（通常是 10/100 Mbps），可与远程设备、其他控制系统或云服务进行数据交互。
• 提供 RS-232/RS-422 串行通信接口，适合与传感器、控制器等设备进行数据传输。

应用领域：

• 工业自动化： 用于PLC控制系统、机器人控制、数据采集系统等。
• 嵌入式计算： 在嵌入式控制系统中，用于处理复杂任务，如过程控制、远程监控等。
• 通信系统： 支持高速数据传输，适用于通信基站、监控系统等。
• 军事与航空航天： 在恶劣环境中运行，提供稳定的计算平台，用于飞行控制、导航系统等。

技术规格：

优点：

• 强大的计算能力和实时处理能力，适用于复杂控制任务。
• 可靠性高，抗干扰能力强，适合恶劣环境。
• 丰富的接口和扩展性，能够连接各种工业设备和系统。
• 支持广泛的操作系统，适应不同的软件平台。

英文资料：

Motorola MVME167-33B is a high-performance industrial control system based on the VMEbus architecture, widely used in embedded computing, industrial automation, data acquisition, communication control and other fields. The system was designed and manufactured by Motorola (now NXP Semiconductors) to provide reliable performance in harsh industrial environments.

Main features of MVME167-33B:

Processor and Performance:

Equipped with a 33 MHz Motorola 68040 RISC processor, it has high processing power and is suitable for applications that require strong computing and real-time control.

Support multitasking operating systems, such as VxWorks, RTEMS, and other real-time operating systems (RTOS), to achieve real-time control functionality.

Memory configuration:

Provide a maximum of 128 MB DRAM (Dynamic Random Access Memory) to meet high bandwidth data processing and storage requirements.

Supports Flash storage (usually 4 MB or larger) for storing firmware, applications, and operating systems.

VMEbus architecture:

Adopting the VMEbus standard, it can provide efficient data transmission speed and scalability, supporting multiple VMEbus modules and peripherals.

Supports VME 64 bit expansion, with higher bandwidth, suitable for data intensive applications.

I/O interface:

Provide multiple serial interfaces (such as RS-232 and RS-422) for communication and data exchange.

Equipped with Ethernet network interface, supporting industrial Ethernet communication and remote data transmission.

Multiple GPIO (General Purpose Input/Output) interfaces that can connect external devices such as sensors and actuators.

Operating system support:

Compatible with multiple real-time operating systems (RTOS), including VxWorks, Linux, RTEMS, etc., flexibly supporting various industrial application requirements.

Basic applications that support DOS and Windows operating systems.

Scalability:

Provide multiple expansion slots, support additional I/O modules and dedicated cards, and can expand functionality according to specific needs.

It has a PMC (PCI Mezzanine Card) slot that allows for the addition of other hardware modules.

Reliability and Durability:

Designed for industrial grade environments, it has high anti-interference ability and thermal stability.

Having strong error detection and fault tolerance capabilities to ensure stable system operation.

Support temperature range: -40 ° C to+85 ° C, suitable for extreme environmental conditions.

Communication and network capabilities:

Supports Ethernet network interface (usually 10/100 Mbps) for data exchange with remote devices, other control systems, or cloud services.

Provide RS-232/RS-422 serial communication interface, suitable for data transmission with sensors, controllers and other devices.

Application areas:

Industrial automation: used for PLC control systems, robot control, data acquisition systems, etc.

Embedded computing: In embedded control systems, it is used to handle complex tasks such as process control, remote monitoring, etc.

Communication system: Supports high-speed data transmission and is suitable for communication base stations, monitoring systems, etc.

Military and Aerospace: Operating in harsh environments, providing a stable computing platform for flight control, navigation systems, etc.

Technical specifications:

Parameter Description

Processor Motorola 68040 33 MHz

Maximum memory of 128 MB DRAM

Maximum storage capacity of 4 MB Flash

VMEbus Standard VME 64 bit

Multiple RS-232, RS-422 serial ports for I/O interface, Ethernet

Network interface 10/100 Mbps Ethernet

Expand multiple VME slots and support PMC

The operating system supports VxWorks, Linux, RTEMS

Working temperature range -40 ° C to+85 ° C

Power demand+5V DC

Reliable anti vibration and dust-proof design, suitable for industrial environments

advantage:

Powerful computing and real-time processing capabilities, suitable for complex control tasks.

High reliability, strong anti-interference ability, suitable for harsh environments.

Rich interfaces and expandability, capable of connecting various industrial equipment and systems.

Supports a wide range of operating systems and adapts to different software platforms.
