GM INTERNATIONAL D1063S 隔离中继器 PDF资料
1.产 品 资 料 介 绍：
中文资料：
GM INTERNATIONAL D1063S 隔离中继器 是一款高性能的隔离设备，用于工业自动化中信号的隔离、转换和传输。它常用于危险环境下的信号保护，以确保安全和数据完整性。
产品特点：
输入信号支持：
- 数字信号输入，支持无源接点或有源电流源。
- 输入类型可配置，以适应不同应用。
输出信号：
- 提供隔离的数字信号输出。
- 适用于驱动PLC、DCS等控制系统的输入模块。
隔离特性：
- 高隔离强度：输入、输出和电源之间隔离，确保安全。
- 隔离等级通常达到2.5 kV或更高。
安全认证：
- 符合 ATEX、IECEx 等防爆认证，适用于危险区域（Zone 0/1/2）。
- SIL（安全完整性等级）认证，适合安全关键应用。
宽电源范围：
- 通常支持24 V DC供电，适应工业现场需求。
可靠性：
- 低功耗设计，提升设备寿命。
- 高抗干扰能力，适用于复杂工业环境。
安装方式：
- 可DIN导轨安装，易于集成到控制柜中。
应用场景：
- 化工、石油和天然气等危险环境中的信号隔离与保护。
- PLC/DCS系统中的信号接口设备。
- 防爆环境中的传感器和执行器连接。
- 电气噪声敏感区域的数据传输。
技术规格（示例）：
| 参数 | 数值 |
|---|---|
| 输入信号 | 无源接点、有源电流 |
| 输出信号 | 开关量 |
| 隔离电压 | 2500 V AC |
| 电源电压 | 24 V DC |
| 工作温度范围 | -20°C 至 +60°C |
| 认证 | ATEX, IECEx, SIL |
优点：
- 提供多重保护，防止信号失真或干扰。
- 通过隔离减少地回路问题。
- 安装便捷，维护简单。
英文资料：
The GM INTERNATIONAL D1063S isolation repeater is a high-performance isolation device used for signal isolation, conversion, and transmission in industrial automation. It is commonly used for signal protection in hazardous environments to ensure safety and data integrity.
Product features:
Input signal support:
Digital signal input, supporting passive contacts or active current sources.
The input type can be configured to adapt to different applications.
Output signal:
Provide isolated digital signal output.
Suitable for driving input modules of control systems such as PLC and DCS.
Isolation characteristics:
High isolation strength: Isolation between input, output, and power supply to ensure safety.
The isolation level usually reaches 2.5 kV or higher.
Security certification:
Compliant with ATEX, IECEx and other explosion-proof certifications, suitable for hazardous areas (Zone 0/1/2).
SIL (Safety Integrity Level) certification, suitable for safety critical applications.
Wide power range:
Usually supports 24V DC power supply to meet the needs of industrial sites.
Reliability:
Low power design enhances device lifespan.
High anti-interference ability, suitable for complex industrial environments.
Installation method:
Can be installed on DIN rails, easy to integrate into control cabinets.
Application scenarios:
Signal isolation and protection in hazardous environments such as chemical, petroleum, and natural gas.
Signal interface equipment in PLC/DCS systems.
Sensor and actuator connections in explosion-proof environments.
Data transmission in areas sensitive to electrical noise.
Technical specifications (example):
Parameter values
Input signal passive contact, active current
Output signal switch quantity
Isolation voltage 2500 V AC
Power supply voltage 24 V DC
Working temperature range -20 ° C to+60 ° C
Certified ATEX, IECEx, SIL
advantage:
Provide multiple protections to prevent signal distortion or interference.
Reduce ground loop issues through isolation.
Easy installation and simple maintenance.
2.产 品 展 示
