ABB T3N225断路器 PDF资料
1.产 品 资 料 介 绍：
中文资料：
ABB T3N225 断路器 是一款来自 ABB T3 系列的中型断路器，专为低压电力系统中的过载和短路保护设计。它广泛应用于工业、商业和建筑电力分配系统中，确保电气设备和线路在出现故障时得到有效的保护。
主要特性和技术参数
额定电流 (In)：
- ABB T3N225 断路器的额定电流为 225 A，适用于中等负载的电气保护。
过载保护和短路保护：
- 过载保护：可以根据实际负载情况设定，防止电流过大导致线路和设备过热、损坏。
- 短路保护：该断路器配备短路保护功能，能够在出现短路情况时迅速断开电路，防止更严重的故障发生。
断路能力：
- T3N225 具有高断路能力，能够应对较高的短路电流，确保在极端情况下能够迅速切断电流，防止电气设备损坏或火灾。
电气性能：
- 瞬时释放 (Instantaneous trip)：当发生短路故障时，瞬时释放特性可确保断路器在极短的时间内断开电路，保护系统免受损坏。
- 时间延迟释放 (Time-delayed trip)：对于较小的过载，T3N225 断路器支持时间延迟释放特性，这有助于防止因短时过载（如启动电流）而不必要的跳闸。
外形和尺寸：
- T3N225 断路器采用紧凑的设计，适用于标准化的电气控制柜和配电盘，确保安装和布线的灵活性和便利性。
- 标准化的尺寸和安装孔距，使得该断路器可以快速替换或安装在现有系统中。
应用范围：
- 商业建筑：用于大型商业建筑的配电系统，保护电气设备免受过载和短路故障影响。
- 工业设备：在制造工厂、工业生产线等场所，作为主要电力分配和保护设备，确保重要电气设施的安全运行。
- 住宅配电：适用于大型住宅小区或多层建筑的电力分配系统中，用于确保电气设备和负载的安全。
- 电力分配和控制系统：T3N225 在电力分配系统中担任着关键角色，确保系统中每条电路的过载保护和短路防护。
耐久性与维护：
- T3N225 断路器具有较长的使用寿命和良好的耐用性，适合于频繁开关操作的环境。
- 该断路器支持简单的维护和检查，可以在不中断电力供应的情况下快速替换或维修。
环境适应性：
- 该断路器设计具有较强的环境适应性，能够在工业环境、建筑工地等较为严苛的工作条件下运行。
- 可以适应广泛的工作温度范围，通常为 -5°C 到 40°C。
英文资料：
The ABB T3N225 circuit breaker is a medium-sized circuit breaker from the ABB T3 series, designed specifically for overload and short-circuit protection in low-voltage power systems. It is widely used in industrial, commercial, and building power distribution systems to ensure effective protection of electrical equipment and lines in the event of faults.
Main features and technical parameters
Rated current (In):
The rated current of ABB T3N225 circuit breaker is 225 A, suitable for electrical protection under medium loads.
Overload protection and short circuit protection:
Overload protection: It can be set according to the actual load situation to prevent excessive current from causing overheating and damage to the circuit and equipment.
Short circuit protection: This circuit breaker is equipped with a short circuit protection function, which can quickly disconnect the circuit in case of a short circuit, preventing more serious faults from occurring.
Circuit breaking capability:
T3N225 has high breaking capacity and can handle high short-circuit currents, ensuring that the current can be quickly cut off in extreme situations to prevent electrical equipment damage or fire.
Electrical performance:
Instantaneous trip: When a short circuit fault occurs, the instantaneous trip feature ensures that the circuit breaker disconnects the circuit in a very short time, protecting the system from damage.
Time delayed trip: For smaller overloads, the T3N225 circuit breaker supports a time delayed trip feature, which helps prevent unnecessary trips due to short-term overloads (such as starting currents).
Appearance and dimensions:
The T3N225 circuit breaker adopts a compact design, suitable for standardized electrical control cabinets and distribution panels, ensuring flexibility and convenience in installation and wiring.
The standardized size and installation hole spacing enable the circuit breaker to be quickly replaced or installed in existing systems.
Application scope:
Commercial buildings: used for power distribution systems in large commercial buildings to protect electrical equipment from overload and short circuit faults.
Industrial equipment: As the main power distribution and protection equipment in manufacturing factories, industrial production lines, and other places, it ensures the safe operation of important electrical facilities.
Residential power distribution: suitable for power distribution systems in large residential communities or multi story buildings, used to ensure the safety of electrical equipment and loads.
Power distribution and control system: T3N225 plays a critical role in the power distribution system, ensuring overload protection and short-circuit protection for each circuit in the system.
Durability and maintenance:
T3N225 circuit breaker has a long service life and good durability, suitable for environments with frequent switching operations.
This circuit breaker supports simple maintenance and inspection, and can be quickly replaced or repaired without interrupting power supply.
Environmental adaptability:
The circuit breaker design has strong environmental adaptability and can operate under harsh working conditions such as industrial environments and construction sites.
It can adapt to a wide range of working temperatures, typically from -5 ° C to 40 ° C.
