Bently 3500/32M 149986-02 继电器模块   PDF资料

1.产 品 资 料 介 绍：

中文资料：

Bently 3500/32M 149986-02 继电器模块 是 Bently Nevada（现为 Baker Hughes 的一部分）生产的高性能监控系统组件。该模块属于 Bently 3500 系列机器保护和监控系统，专门设计用于处理和管理机器故障报警及相关控制信号，广泛应用于工业设备的保护、故障诊断和状态监测系统中。

主要特点：

1. 继电器输出功能：

• 3500/32M 继电器模块提供多个继电器输出通道，用于机器监控系统中的报警、故障指示和保护控制。继电器输出通常会驱动外部报警装置、停机控制、阀门或其他执行器。

2. 高可靠性和冗余设计：

• 该模块采用高可靠性的设计，能够在工业环境中提供稳定、无故障的工作，确保机器设备的长期安全运行。模块内有冗余配置，保证即使在单个继电器故障的情况下，系统依然可以持续工作。

3. 多通道输出：

• 通常，Bently 3500/32M 模块包括多个输出通道，可以配置用于不同的报警和控制需求。例如，一些通道可能用于机器状态报警（如振动过高），而另一些通道用于机器运行状态（如启动或停止）。

4. 兼容性与易集成性：

• 该继电器模块与 Bently 3500 系列 系统中的其他组件（如 3500/22M 输入模块、3500/42 传感器模块 等）兼容，能够无缝集成到现有的机器监控系统中。支持标准的工业通讯协议，便于与其他自动化控制系统连接。

5. 状态指示与诊断功能：

• 3500/32M 模块带有状态指示灯和诊断功能，帮助运维人员实时了解模块的运行状态。通过可视化的指示灯，用户可以快速判断每个继电器的状态，便于故障排查和维护。

6. 防护和抗干扰：

• 该模块具有良好的抗电磁干扰能力，能够在复杂的工业环境中稳定工作，特别适用于电气噪声较大的环境，如大型机械设备或高电压设备附近。

7. 高温工作环境：

• 3500/32M 继电器模块设计具备较强的耐高温能力，能够在极端温度下工作，适应温度波动较大的工业环境。

技术规格：

• 型号：Bently 3500/32M 149986-02
• 类型：继电器模块
• 输出类型：多个继电器输出，支持开关控制信号（如高/低报警、设备启停等）
• 输入信号：通常与 Bently 3500 系列输入模块 配合使用，接收来自传感器或其他监控设备的输入信号。
• 输出容量：每个继电器输出通常支持一定的负载电流（例如，AC/DC 额定电压和电流），满足工业自动化中各种控制需求。
• 工作温度范围：广泛的工作温度范围（通常为 -40°C 至 +70°C），适应多种工业环境。
• 通讯接口：支持标准工业通信协议，如 Modbus RTU、Profibus DP 或 Ethernet/IP，便于与控制系统的其他部分连接。
• 尺寸与安装：模块通常采用标准的 19 英寸机架安装方式，方便在控制柜中进行安装。

英文资料：

The Bently 3500/32M 149986-02 relay module is a high-performance monitoring system component produced by Bently Nevada (now part of Baker Hughes). This module belongs to the Bently 3500 series machine protection and monitoring system, specifically designed to process and manage machine fault alarms and related control signals. It is widely used in industrial equipment protection, fault diagnosis, and status monitoring systems.

Main features:

Relay output function:

The 3500/32M relay module provides multiple relay output channels for alarm, fault indication, and protection control in machine monitoring systems. Relay outputs typically drive external alarm devices, shutdown controls, valves, or other actuators.

High reliability and redundant design:

This module adopts a high reliability design, which can provide stable and fault free operation in industrial environments, ensuring the long-term safe operation of machinery and equipment. The module has redundant configurations to ensure that the system can continue to operate even in the event of a single relay failure.

Multi channel output:

Typically, Bently 3500/32M modules include multiple output channels that can be configured for different alarm and control requirements. For example, some channels may be used for machine status alarms (such as high vibration), while others may be used for machine operating status (such as start or stop).

Compatibility and ease of integration:

This relay module is compatible with other components in the Bently 3500 series system, such as the 3500/22M input module, 3500/42 sensor module, etc., and can be seamlessly integrated into existing machine monitoring systems. Supports standard industrial communication protocols for easy connection with other automation control systems.

Status indication and diagnostic function:

The 3500/32M module is equipped with status indicator lights and diagnostic functions to help operation and maintenance personnel understand the real-time operation status of the module. Through visual indicator lights, users can quickly determine the status of each relay, facilitating troubleshooting and maintenance.

Protection and anti-interference:

This module has good electromagnetic interference resistance and can work stably in complex industrial environments, especially suitable for environments with high electrical noise, such as large mechanical equipment or high voltage equipment.

High temperature working environment:

The 3500/32M relay module design has strong high-temperature resistance and can operate at extreme temperatures, adapting to industrial environments with large temperature fluctuations.

Technical specifications:

Model: Bently 3500/32M 149986-02

Type: Relay Module

Output type: Multiple relay outputs, supporting switch control signals (such as high/low alarm, equipment start stop, etc.)

Input signal: Typically used in conjunction with Bently 3500 series input modules, it receives input signals from sensors or other monitoring devices.

Output capacity: Each relay output typically supports a certain load current (e.g. AC/DC rated voltage and current), meeting various control requirements in industrial automation.

Working temperature range: A wide range of working temperatures (usually -40 ° C to+70 ° C), suitable for various industrial environments.

Communication interface: Supports standard industrial communication protocols such as Modbus RTU, Profibus DP, or Ethernet/IP, making it easy to connect with other parts of the control system.

Size and Installation: Modules are typically installed using standard 19 inch rack mounting methods, making it easy to install in control cabinets.
